A Study on the Occurrence of Discouloration / Blackening / Dezincification / Corrosion on 7.62 mm Ball Ammunition Manufactured by Ordnance Factory Varangaon

Abstract

This study examines the persistent degradation of 7.62 mm ball ammunition from Ordnance Factory Varangaon (OFV), characterized by unwanted changes in appearance and structural integrity. Using a combined analytical and qualitative approach, the research assesses the success of modified protective treatments, the role of sulfur-based contaminants, and the effects of storage and packaging. Key results demonstrate that sulfur, originating from packaging and wax, is a significant cause of surface blackening. Furthermore, while the new protective coating process requires thorough confirmation, relying solely on immersion cleaning proves insufficient for preventing recurring corrosion. The research concludes by suggesting ways to refine the protective coating process, investigate new cleaning techniques, and establish a system of continuous assessment to enhance product quality and user satisfaction. This research provides insights into quality management within ammunition manufacturing, emphasizing the need for robust evaluation, process verification, and innovative approaches to solve longstanding corrosion and degradation problems.

Introduction

Since 2012, multiple depots reported blackening (discoloration) of 7.62mm belted ammunition cartridge cases. Initial inspections by SQAE(A) Varangaon from 2013 onward identified the issue and approved hand rumbling with toluene and cotton as a temporary rectification method. Later, CQA(Met) confirmed chromic acid solution effective in removing black stains, though toluene remained in use.

A Board of Officers (BOO) investigated and recommended stricter quality control on packing materials, including millboard, wax, and gaskets, which were found to contribute sulfur contamination—identified as the primary cause of blackening. The presence of sulfur in wax, cleaning chemicals, and packing materials was confirmed by tests from various labs including CSIR-NML.

A Study Group and Task Force formed by CQA(A) recommended switching packing materials to PPC (polypropylene corrugated sheets) and adopting dip cleaning methods using chemical solutions developed by CSIR-NML for better rectification. OFV made changes in manufacturing, including chemical passivation and removal of previous cleaning steps, but continued blackening issues persisted, partly due to proprietary chemicals whose specifications were not disclosed.

Trials and testing from 2015 to 2024 included different cleaning and passivation methods. The chromate passivation process at OFV was found to be non-compliant with specifications (JSS 0461-01) and inconsistently applied, possibly causing poor passivation and contributing to blackening.

Recommendations include fully automating the chromate passivation process, replacing packing carton materials with non-sulfur-containing alternatives, and continuing dip cleaning as a corrective method until better processes are implemented. Some blackened lots were segregated, rectified, and reissued after proof testing, while worst-affected rounds were discarded.

Despite ongoing improvements, blackening remains a concern, with debates over whether it is caused by storage environment, chemical contamination, or natural brass aging. Recent audits stressed the need for strict adherence to specifications and improved packaging to prevent recurrence.

Conclusion

This study investigated critical facets of the revised passivation process validation, the efficacy of dip cleaning, and the contentment with implemented corrective measures. Utilizing a range of statistical techniques, including chi-square tests, logistic regression, paired t-tests, and ordinal regression, several key findings were identified. Initially, the validation of the altered passivation procedure (H1) revealed no notable correlation between respondent experience and their assessment of the validation. This implies that experience did not impact perceptions of the process\'s efficacy. Secondly, the dip cleaning\'s effectiveness (H4) was statistically insignificant, as both the paired t-test and logistic regression demonstrated that it did not substantially mitigate corrosion recurrence. This underscores the necessity to investigate alternative or complementary cleaning approaches to better address corrosion issues. Concerning satisfaction with corrective actions (H5), the analysis indicated that although overall contentment was average, the passivation process\'s effectiveness significantly predicted increased satisfaction. However, satisfaction levels remained consistent across different roles, suggesting a shared perception of the corrective measures. These results point to the potential for enhanced overall satisfaction among stakeholders by improving the passivation process\'s effectiveness. In conclusion, the hypothesis testing outcomes emphasize the significance of refining the passivation process and seeking alternative solutions to boost both effectiveness and satisfaction. While some hypotheses did not yield significant outcomes, they offer valuable insights into areas demanding further study and potential enhancements. Subsequent research could concentrate on pinpointing additional factors influencing corrosion recurrence and satisfaction, and also on evaluating novel methods to improve the general efficacy of corrective actions.

References

[1] Murugesan Committee Report (Final Report of Task Force on blackening of 7.62 mm Seq Belted Amn). [2] CSIR-NML (National Metallurgical Lab, Jamshedpur) report on development of cleaning methodology for removal of black layer on Cartq 7.62 mm Seq Belt. [3] JSS Specification No 0461-01:2019 on Passivation of Brass components of Cartg cases, Fuze, Primers etc. [4] CQA(A), Khadki letter No QA13200/Blackening dt 06 Jun 2015. [5] Minutes of Collegiate Meeting held at MGO Branch under the Chairmanship of Maj Gen JS Menon, ADG EM for rectification of Amn (2.5 Crore) on 04 Dec 15 forwarded vide their letter No B/819010/7.62mm Belted/MGO/EM (Armt, SA & A) dt 11 Dec 15. [6] CQA(A), Khadki letter No QA13200/Blackening/lSAT dt 31 Dec 2015. [7] CQA(A), Khadki letter No QA13200/7.62mm/Blackening/Fresh dt 05 Feb 2016. [8] BOO from 05 Dec 2022 to 09 Dec 2022 at 31 Fd Amn Depot, Clo 99 APO to carry out inspection of Qty 4578261 of AMK-50G Carts SA 7.62 mm ball A-7 MK II. [9] Board proceeding of joint in-situ inspection of AMK 50G, Cartg SA 7.62 mm Ball A- 7 carried out by rep of Ord Fy Varangoan & SQAE (A) Varangaon at 14 Field Arnn Depot on 12 Dec 2022. [10] CQA(A) Khadki letter No QA13318/A-7/IND dated 18 Aug 2022. [11] CQA(Met) letter No CQA(M)/QA-2/7.62mm/AmnNol-09 dated 11 Apr 2022. [12] CQA(Met) letter No CQA(M)/QA-2/7.62mm/AmnNol-09 dated 15 Dec 2021. [13] HQ DQA(A) letter No 95344/12.7 & 7.62mm Amn/DGQA/Arm-5 dated 01 May 2017. [14] CAD Pulgaon letter No 3602C/GenNol-l/335/Cont/Receipt dt 13 Nov 2021. [15] CAD Pulgaon letter No 3602C/GenNol-lll/159/Cont/Receipt dt 17 Dec 2021. [16] CAD Pulgaon letter No 3602C/GenNol-lll/170/Cont/Receipt dt 29 Jan 2022. [17] CAD Pulgaon letter No 3602C/OFVNol-l/26/Cont/Receipt dt 24 Jun 2022. [18] CAD Pulgaon letter No 3602C/OFVNol-I/45/Cont/Receipt dt 04 Aug 2022. [19] CAD Pulgaon letter No 3602C/OFVVol-/48/Cont/Receipt dt 06 Sep 2022. [20] CAD Pulgaon letter No 3602C/OFVNol-l/63/Cont/Receipt dt 07 Oct 2022. [21] Minutes on Defect Investigation of AMK-50G, Carts SA 7.62mm Ball A-7 Mk-II Amn (qty 562699) at CAD Pulgaon from 20 Oct 2022 to 22 Oct 2022. [22] In-Situ Joint Investigation Report of Blackened Ammunition of Cartg SA [23] 7.62X39 MM BALL A-7 Lot No 004 OFV 06-2018 12 BN BSF Akhnoor on 13/09/2022. [24] Board of Officers in-situ joint investigation of blackened Carts SA 7.62mm A-7 Amn of lots at 15 FAD on 22 to 23 Sep 2022. [25] Board of Officers in-situ joint investigation of blackened Carts SA 7.62mm A-7 Amn of lots at 10 Inf DOU (101 AP) on 26 Sep to 27 Sep 2022. [26] Board of Officers in-situ joint investigation of blackened Carts SA 7.62mm A-7 Amn of lots at 21 FAD on 16 to 20 Sep 2022. [27] Board of Officers in-situ joint investigation of blackened Carts SA 7.62mm A-7 Amn of lots at GC CRPF, Greater Noida (U P) on 30/09/2022 to 01/10/2022. [28] CQA (Met) Metallurgical Investigation Report of Defect with Amn AMK-50 G Cartg SA 7.62 mm Ball A-7 MK-II Amn dt 10 Aug 2021. [29] References to Accelerated Tarnish resistance tests – Humidity Chamber test & Sodium Sulfide Test. [30] SQAE (A) Varangaon Letter No QAV/A-7/ Blackening/II Dt 05 Aug 2022. [31] SQAE (A) Letter No QAV/A-7/ Blackening/II Dt 18 Jul 2022. [32] CQA (Met) Letter No CQA (M) /QA-2/7.62mm/Amn/Vol-09 Dt 31 May 2022. [33] CQA (Met) Letter No CQA (M) /QA-2/7.62mm/Amn/Vol-09 Dt 11 Apr 2022. [34] SQAE (A) Varangaon Letter No QAV/A-7/Blackening/II Dt 30 Mar 2022. [35] CQA (A) letter of even No Dt 03 Feb 2022. [36] OFV Letter No 1125/OFV/TC/SQAE (A) Dt 23 Mar 2022. [37] CQA (A) Letter No of even No Dt 19 Jan 2022. [38] CQA (Met) Letter No CQA (M)/QA-2/7.62mm/Amn/Vol-19 Dt 15 Dec 2021. [39] CSIR NML Jamshedpur Project report Dt 2015. [40] BOO on spl insp of qty 77760 of AMK-50G, Carts SA 7.62 mm Ball AK-47 carried out by the tech rep of 33 FAD on 06 Jun 2022 as directed by CAD Pulgaon. [41] Board of Officers in-situ joint investigation of blackened Carts Carts 5.56mm Ball CTN arnn (qty 1425600) and Carts SA 7.62mm Ball A-7 MK-II (qty 751047) at CAD Pulgaon from 27 Jun 2022 to 01 Jul 2022. [42] Trial Report for Process Improvement in Passivation of Case by OFV in association with SQAE(A), Varangaon Dated23/11/2021. [43] MOM in CQA(A) on 25 Oct 2023. [44] Feedback report by Shri K Sharan, AE(QA) on actions at 15 FAD from 23 – 25 Nov 2023. [45] CQA(A) letter No QA13318/A-7/IND dt 18 Dec 2023. [46] MOM in CQA(A) on 26 Dec 2023. [47] Draft SOP prepared in view of carrying out inspection of stores against which blackening / discoloration observed in the ammunition supplied by Ordnance Factories. [48] Arora, K. C. (2009). Production and Operations Management. Laxmi Publications. [49] Heizer, J., & Render, B. (2020). Operations Management: Sustainability and Supply Chain Management (13th ed.). Pearson. [50] Journal of Materials Performance and Characterization (2022). Evaluation of corrosion resistance in nickel-plated brass casings. Journal of Materials Performance and Characterization, 11(4), 345–356. [51] International Journal of Corrosion (2021). Chloride-induced stress corrosion cracking in ammunition-grade brass. International Journal of Corrosion, 2021, 1–9. [52] Materials and Design (2020). Advances in nanostructured coatings for corrosion inhibition. Materials and Design, 194, 108942. [53] Military Engineering Magazine (2023). Climate-controlled storage techniques for long-term ammunition preservation. Military Engineering Magazine, 58(3), 12–18. [54] Surface and Coatings Technology (2022). Protective coatings for military-grade metals: A review. Surface and Coatings Technology, 436, 128292. [55] Journal of Electrochemical Science and Engineering (2022). Electrochemical corrosion in steel and brass ammunition: Mechanisms and protection strategies. Journal of Electrochemical Science and Engineering, 12(2), 99–116. [56] Defense Manufacturing Journal (2022). Advances in materials for small arms ammunition: Enhancing durability and performance. Defense Manufacturing Journal, 37(4), 45–53. [57] Corrosion Science (2021). Dezincification of brass alloys in marine environments: Experimental studies and implications. Corrosion Science, 181, 109–123. https://doi.org/10.1016/j.corsci.2020.109123. [58] Materials Performance Magazine (2020). Industrial corrosion of brass: Implications for small arms ammunition. Materials Performance, 59(5), 34–41. [59] DebRoy, T., Wei, H. L., Zuback, J. S., Mukherjee, T., Elmer, J. W., Milewski, J. O., ... & Zhang, W. (2018). Additive manufacturing of metallic components: Process, structure, and properties. Progress in Materials Science, 92, 112–224. https://doi.org/10.1016/j.pmatsci.2017.10.001. [60] Wang, K. (2020). Industry 4.0: Concepts, Technologies, and Applications. Springer. [61] International Journal of Advanced Manufacturing Technology (2023). Additive manufacturing in defense industries: Current trends and future prospects. International Journal of Advanced Manufacturing Technology, 127(3), 1234–1249. [62] Additive Manufacturing Journal (2022). Innovations in 3D printing for advanced manufacturing. Additive Manufacturing Journal, 47(1), 89–101. [63] Quality Progress Magazine (2023). Smart manufacturing: The impact of IoT and AI in production. Quality Progress, 56(5), 21–29. [64] Defense Manufacturing Journal (2023). Industry 4.0 and the future of ammunition production. Defense Manufacturing Journal, 35(2), 45–52. [65] Chiarini, A. (2012). From Total Quality Control to Lean Six Sigma: Evolution of the Most Important Management Systems for the Excellence. Springer. [66] Lee, J., & Bagheri, B. (2015). Cyber-Physical Systems in Modern Manufacturing. Springer. [67] Montgomery, D. C. (2020). Quality management and data-driven insights: The impact of standards. Quality Engineering, 32(4), 529–540. https://doi.org/10.1080/08982112.2020.1713567. [68] Nahmias, S., & Olsen, T. L. (2015). Production and Operations Analysis (7th ed.). Waveland Press. [69] Stevenson, W. J. (2021). Operations Management (14th ed.). McGraw-Hill Education. [70] Black, J. T. (2008). Lean Production: Implementing a World-Class System. Industrial Press. [71] Shingo, S. (1989). A study on the Toyota production system: From an industrial engineering viewpoint. International Journal of Production Research, 27(6), 801–820. [72] Evans, J. R., & Lindsay, W. M. (2019). Managing for Quality and Performance Excellence (11th ed.). Cengage Learning. [73] Gunasekaran, A., Subramanian, N., & Rahman, S. (2015). Operations management in the era of Industry 4.0: Challenges and opportunities. International Journal of Production Economics, 164, 221–231. [74] Sanders, R. E. (2012). CNC Machining Handbook: Building, Programming, and Implementation. Industrial Press. [75] Groover, M. P. (2020). Automation, Production Systems, and Computer-Integrated Manufacturing (5th ed.). Pearson. [76] Womack, J. P., Jones, D. T., & Roos, D. (2007). The Machine That Changed the World: The Story of Lean Production. Simon & Schuster. [77] Eva-Dry. (2024). How to Preserve and Protect Your Firearms and Ammunition from Moisture. Retrieved from www.eva-dry.com. [78] Defense and Munitions. (2024). Corrosion Prevention for Military Weapons and Equipment. Retrieved from www.defenseandmunitions.com. [79] Cortec Corporation. (2024). Effective Use of VpCI Technology in Ammunition Preservation. Retrieved from www.cortecvci.com. [80] ISO 9001:2015, Quality Management Systems—Requirements. [81] Likert, R. (1932). \"A Technique for the Measurement of Attitudes.\" Archives of Psychology, 140, 1-55. [82] Dolnicar, S., & Grün, B. (2013). “Translating Between Survey Question Formats.” Journal of Business Research, 66(9), 1296-1303. [83] Ishikawa, K. (1982). Guide to Quality Control. Tokyo: Asian Productivity Organization. [84] Dillman, D. A., Smyth, J. D., & Christian, L. M. (2014). Internet, Phone, Mail, and Mixed-Mode Surveys: The Tailored Design Method. [85] ISO 19011:2018, Guidelines for Auditing Management Systems. [86] Fowler, F. J. (2013). Survey Research Methods. 5th ed. SAGE Publications.
