Comparative Seismic Performance of RCC Beam with Rebar and Post Tensioned PSC Beam Using LRPC Strands with M35 Grade on Hard Soil

Abstract

India has been identified among the most densely populated countries in the world, as per recent statistics. A severe shortage of urban land has been experienced due to this high population density. To ensure maximum spatial efficiency, buildings with aesthetic appeal have been engineered using RCC technology. In recent constructions, the advantages of Prestressed Concrete (PSC)—including lower material usage and higher structural strength—have not been fully considered. The substitution of RCC with PSC, while maintaining stability, has been regarded as the principal challenge. A systematic review of literature focusing on PSC implementation and techniques was undertaken in this dissertation. The gap in the research field was noted, as no analytical study has been reported involving post tensioned PSC beams with LRPC strand cables. Multiple simulation cases were performed using advanced structural analysis software for a commercial building model. Different structural cases with PSC beams at various floor levels were analyzed and later optimized into categories ranging from PSC-LRPC-B to PSC-LRPC-M. These optimized cases were subsequently compared against a standard RCC structure labeled RCC-REBAR-A. Key performance indicators such as beam deflection, shear force, bending moment, and total base shear under seismic effects were carefully assessed. Limiting capacities of beam resistance were investigated using these parameters and thoroughly examined. In a G+10 residential building scenario, considerable reductions in beam size were achieved using optimized PSC members. Cross sectional areas of beams were reduced by a minimum of 11.11% and a maximum of 78.79%, depending on the floor level. Finally, economic benefits were realized, as the reduction in member sizes due to PSC implementation was found to correlate with overall cost savings.

Introduction

Prestressed Concrete (PSC) systems enhance structural performance by introducing internal compressive stresses through tensioned steel tendons, either pre-tensioned before casting or post-tensioned after concrete hardening. This technique improves flexural strength, crack resistance, and reduces deflections, making PSC ideal for large-span bridges, high-rises, and critical infrastructure by boosting durability and lifespan.

There are two main types of PSC:

• Pre-Tensioned Concrete: Tendons are tensioned before pouring concrete, commonly used in factory-made elements.

• Post-Tensioned Concrete: Tendons are tensioned after concrete has gained strength, suited for cast-in-place structures like floors and bridges.

Research objectives focus on analyzing PSC beam designs in a multistory building using STAAD Pro software and the Response Spectrum Method. The study aims to:

• Calculate internal forces, deflections, shear forces, and bending moments in PSC beams.

• Compare PSC performance against conventional RCC beams in terms of strength and serviceability.

• Conduct seismic base shear analysis in two directions.

• Optimize beam dimensions to reduce size and material usage.

Modeling and analysis involved a 3D structural model of a G+10 residential building on hard soil (Seismic Zone III), using M35 concrete and Fe550 steel. A single 12.7 mm low-relaxation post-tensioning cable per beam was used with specific prestressing stresses. Building parameters, including dimensions of beams, columns, slabs, and shear walls, were standardized, with dynamic properties calculated for seismic response.

Conclusion

The conclusion can be pointed out are as follows:- 1) The modelling of various PSC beam cases at multiple floor levels in a residential apartment has successfully completed over hard soil. 2) The application forces necessary for inducing post tensioning effects have accurately calculated and implemented. 3) Deflection values within the beam elements were recorded and it has found through comparative analysis that optimized PSC beams with reduced cross sectional areas produced deflections within permissible limits, maintaining structural performance. 4) Shear force values in beam members were computed and the study revealed that PSC beams showed a significant reduction ranging from 3.84 % to 55.23 %, all within permissible range. 5) Bending moment values obtained from analysis demonstrated that optimized PSC beams led to reductions from 4.14 % up to 69.72 %, without exceeding the permissible range. 6) Base shear responses for the entire building in both horizontal directions (X and Z) have analysed and a consistent decrease has observed when PSC beams have used. 7) Overall, when RCC section replaced by PSC section resulted in a reduction of cross sectional area ranging from 11.11 % to 78.79 %, confirming the efficiency of the proposed design approach over hard soil. Concluding the research, the comparison of all structural performance parameters indicated that replacing RCC beams with PSC beams at selected floor levels improves efficiency. The post tensioning method in apartments not only ensures structural adequacy but also facilitates a substantial reduction in beam cross sectional area, thereby decreasing the total material consumption. As a result, this approach is highly recommended for adoption in residential apartments, where living is a priority, offers both cost efficiency and structural performance advantages.

References

[1] Agnieszka Wdowiak-Postulak, František Bahleda and Jozef Prokop, (2023), “An Experimental and Numerical Analysis of Glued Laminated Beams Strengthened by Pre-Stressed Basalt Fibre-Reinforced Polymer Bars”, materials, Vol. 16, paper 2776, pp. 1-14. [2] Arpit Shrivastava, Dr. Savita Maru, (2023), “A Review on Different Types of Bridge Girders and Different Tendon Profiles”, International Journal for Research in Applied Science & Engineering Technology (IJRASET), ISSN: 2321-9653, Vol. 11, Issue 11, pp. 1636-1643. [3] Chao LU, Kenan WANG, Shiliang HAN, Zhenzhe SHI, Jiantao ZI and Qunfu LU, “Application of Prestress in Construction of Building Engineering”, Hydraulic and Civil Engineering Technology VII, ATDE220883, pp. 316-325. [4] Dr. Engr Gana, A. J., Toba A. peter and Okoye, S. S. C., (2015), “ASSESSMENT OF PRESTRESSED CONCRETE APPLICATIONS IN NIGERIA CONSTRUCTION SECTOR TOWARD INFRASTRUCTURAL STABILITY AND NATIONAL DEVELOPMENT”, International Journal of Development Research, Vol. 5, Issue 04, pp. 4050-4054. [5] Jakub Kral’ovanec, František Bahleda, Jozef Prokop, Martin Morav?cík and Miroslav Neslušan, (2021), “Verification of Actual Prestressing in Existing Pre-Tensioned Member”, applied sciences, 11, 5971, pp. 1-11. [6] Jakub Kralovanec, Frantisek Bahleda and Martin Moravcik, (2022), “State of Prestressing Analysis of 62-Year-Old Bridge”, materials, 15, 3583, pp. 1-21. [7] Jakub KRA?OVANEC, Martin MORAV?ÍK, (2022), “Experimental Measurements in The Field of Prestressing Force Monitoring”, Civil and Environmental Engineering, Vol. 18, Issue 1, pp. 104-110. [8] Jakub KRA?OVANEC, Martin MORAV?ÍK, Jozef JOŠT, (2021), “Analysis of Prestressing in Precast Prestressed Concrete Beams”, sciendo, Civil and Environmental Engineering, pp. 1-8. [9] Jakub KRA?OVANEC, Martin MORAV?ÍK, Petra Buj ?náková, Jozef JOŠT, (2021), “Indirect Determination of Residual Prestressing Force in Post-Tensioned Concrete Beam”, materials, 14, 1338, pp. 1-17. [10] Michal Zahuranec, Peter Koteš and Jakub Kral’ovanec, (2023), “The Influence of the Prestressing Level of the Fully Threaded Anchor Bar on the Corrosion Rate”, buildings, 13, 1592, pp. 1-16. [11] Narendra Singh, Dr. Savita Maru, (2023), “Seismic Behaviour PSC Box Girder and PSC Precast I Girder Bridge”, International Journal for Research in Applied Science & Engineering Technology (IJRASET), ISSN: 2321-9653, Vol. 11, Issue 3, pp. 1576-1583. [12] Nirajan Kumar Jha, Dr. Shubham Goswami, (2024), “Precast and Pre-Stressed Construction Technology for High Rised Residential Buildings”, International Journal of Creative Research Thoughts (IJCRT), ISSN: 2320-2882, Vol. 12, Issue 6, pp. 583--598. [13] Niranjan. B. Satyannavar, Dr. R. Subhash Chandra Bose, K.M. Shivashankar, (2022), “Design and Analysis of Prestressed Shell Roof Structures”, International Journal for Research in Applied Science & Engineering Technology (IJRASET), ISSN: 2321-9653, Volume 10 Issue 7, pp. 1117-1127. [14] Petra BUJNAKOVA, Jakub KRALOVANEC, Zbigniew PERKOWSKI, Abdelhamid BOUCHAIR, (2022), “VERIFICATION OF PRECAST CONCRETE GIRDER BRIDGE UNDER STATIC LOAD”, sciendo, Civil and Environmental Engineering, 0070, pp. 1-8. [15] Phani Ram Gollapudi, Satish Chandra Dendukuri, Satish Brahmalla, (2024), “Grillage Analysis of Prestressed Concrete Girder Deck Superstructure for NH-16 Bridge Flyover; Part-1”, International Journal for Research in Applied Science & Engineering Technology (IJRASET), ISSN: 2321-9653, Vol. 12, Issue 1, pp. 808-817. [16] Pradeep Nath Mathur, Prof (Dr.) A. K. Sinha, Prof. (Dr.) P.B.L. Chaurasia (2015), “The pre- stress concrete structure, found to-be more effective than the reinforced concrete structure & System developed for mechanism of, anchoring devices in pre and post tensioned concrete structural elements.”, American Journal of Engineering Research (AJER), ISSN: 2320-0847, Vol. 4, Issue 4, pp. 40-49. [17] Ratanak Mony, (2024), “An Investigation of Seismic Behaviour of Prestressed Concrete Frame Structures using Pushover Analysis”, International Journal for Research in Applied Science & Engineering Technology (IJRASET), ISSN: 2321-9653, Vol. 12, Issue 7, pp. 572-587. [18] Ravindra Balawane, Sumit Satao, Sneha Mirje, Shivani Gharde, Prof. Manoj U Deosarkar, (2022), “A Review on Analysis and Design of Prestressed Concrete Bridge by CSiBridge Software”, International Journal for Research in Applied Science & Engineering Technology (IJRASET), ISSN: 2321-9653, Volume 10 Issue 11, pp. 1966-1970. [19] Satoru Fukai (2000), “Application of High-Rise Precast Prestressed Concrete Buildings in High-Seismicity Regions”, 12WCEE, paper 2191, pp. 1-8. [20] Vaibhav G Tejani, Hitesh K Dhameliya, Jasmin Gadhiya (2015), “Review for Study of Prestressing Systems for all Structural Element”, International Journal of Scientific Research in Science, Engineering and Technology, ISSN: 2395-1990, Vol. 1, Issue 6, pp. 369-372. [21] Yogesh Poptani, Prerna Girepunje, Lokesh Singh, (2019), “Analysis of Behaviour of Post Tensioning Slab for Various Framing Under the Influence of Lateral Load”, International Journal of Scientific Research in Civil Engineering, Vol. 3, Issue 06, pp. 2456-6667.
