The green power generation such as solar, wind can also meet the load profile. The goal is to tap the output from different sources using the combination of the PV solar, battery and wind using the power electronics converters system. Excess electricity is injected into grid which charges/discharge the battery when needed. PV solar generationand battery\'s cycling are employed by dual-directional buck-boost converter. Wind power is used by a transformer connected dual half bridge converter. A monophase phase inverter guarantees the converted output to the grid. This system disturbs with fewer number of converters and with just six power electronics switches by whose size and cost is minimized.The control of twol dc–dc converter for grid connected PV, wind and battery configuration based on multi source transformer connected has been addressed. The primary goal is while not compromising the fundamental requirement this system balances the supply as well as the load requirements, to optimize the distribution of energy from various inputs, to regulatethe supply from the green power sources that enhances stability and efficiency of the configuration. Thebidirectional dc-dc converter simulation for grid connected hybrid PV, wind and battery systems utilizing multi-sources input transformer and Simulink outputs are showcased on Matlab.
Introduction
Background & Motivation:
Rising power demand and pollution from conventional fuels drive the shift toward non-conventional, eco-friendly energy sources like solar and wind. Combining these into a hybrid system improves reliability and performance. Batteries are integrated for energy storage to address intermittent generation and supply power during low production or high demand periods.
System Overview:
Hybrid system combines PV solar panels, wind turbines, and a battery.
Energy is managed via a multi-source transformer and two-way bidirectional DC-DC converters to integrate, store, and supply power efficiently.
The system uses a multi-input transformer topology (fully, partially, or non-isolated) to combine energy from solar, wind, and battery sources.
A high-frequency isolation transformer provides galvanic isolation and voltage step-up.
Power conversion stages include:
Bidirectional buck-boost converter for PV and battery management.
Transformer-coupled dual half-bridge boost converter for wind power harvesting.
Full-bridge inverter to connect and supply AC power to the grid.
Key Features:
Reduces number of conversion stages and power electronics components (only six switches), enhancing system efficiency and compactness.
Uses a dual DC-link system for flexible energy flow control.
Controls battery charging/discharging based on power availability and demand.
Ensures stable, uninterrupted power supply to the grid.
Utilizes control strategies based on duty cycle modulation to balance power among sources and load.
Magnetic coupling and multi-port transformer topology enable seamless integration of multiple sources without complexity increase.
Control and Operation:
Power flows managed by equations balancing voltages and currents of PV, wind, battery, and grid.
Switching states of converters (e.g., T3, T4) regulate energy transfer and storage.
Simulation models developed in MATLAB/Simulink demonstrate:
Power flow management.
Voltage and current behavior under varying source availability.
Effective response to changing solar or wind input conditions.
Conclusion
The suggested system \"dua`l directional dc-dc converter for grid integrated PV, wind along with battery systems based on multi-source transformer\" possesses a sophisticated integration to achieve the greatest amount of power from a renewable power source. The power conversion system assists in converting the necessary conditions. The suggested system possesses an easy modeling, uses fewer conversion systems and switches that makes it more comprehensible. It provides a stable and efficient operation without influencing the service of a battery. Power management technique is also witnessed among different sources. The organized system is illustrated in a MATLAB/Simulink and results are presented in this paper.
