Monitoring Landform Dynamics of Mahi River Estuary at Gulf of Cambay, Gujarat Using RS-GIS Techniques

Abstract

The Gulf of Cambay (GoC), the extension of the Arabian Sea, is the valuable asset and is importantfor the economic progress of the state and the nation.This study is focused on estuary of Mahi River and its tributary at Gulf of Cambay (GoC).The studiesshows arising complications of mix nature in a regiondue to several reasons.To detect and assess the decadal landform changes for the 1978-2017 time frame and Level I & II Classification System for Coastal Land Use Mapping for the geology and geomorphological features were considered. Satellite data were used in ArcGIS environment to construct the geo-data sets and produce LULC classified thematic maps and geo-statistics. Statistical analysis generated were materialised to reveal the outcomes. Industries (7%), mangroves (>1%), settlements (>1%) depict a growth from 1978 to 2017. Sandbars have negative and mudflats have positive but fluctuating trend. Further association of classified and predictable features on image were established with Ground Control Points (GCP). The spatial extent of mud flats, salt encrusted land and sand bars have transformed indicating the natural parameters are under pressure over this region. The trend of fluvial water and rejuvenation through sediment flux in gulf in the recent time is declining compare to previous and in contradictory, the spatial extent of mud of marine nature and its deposition and change in its quality is striking and evident.

Introduction

The coastal zone is a complex, transitional area where land and sea interact, encompassing ecosystems with high biological productivity influenced by tides, sediments, and nutrients. Definitions vary, but broadly include intertidal and subtidal zones extending to the continental shelf, with the coastal zone housing 40% of the world’s population within 100 km and covering over 10% of Earth's surface.

The Gulf of Cambay (Khambhat) on Gujarat’s western coast, India, hosts the Mahi River estuary—a critical ecological zone supporting diverse species but vulnerable to pollution and human impact. Human activities such as urbanization, industrialization, and infrastructure development have increasingly altered coastal ecosystems worldwide, including in Gujarat where coastal population and urban growth are significant.

Remote sensing (RS) and GIS technologies, using satellite imagery from Landsat and IRS, have been utilized to monitor land use/land cover (LULC) changes and geomorphological dynamics in the Mahi estuary region from 1978 to 2017. These tools help assess natural processes and anthropogenic influences, such as changes in mudflats, mangroves, agriculture, and industrial land cover.

The study found stable agricultural land and vegetation (~30-35%), slight population growth, but significant increases in industrial areas and fluctuating mudflat extents—reflecting the complex interplay between natural sedimentation and human pressures like dam construction, pollution, and urban encroachment. The estuary’s sediment supply has decreased due to these impacts, threatening its ecological balance.

Field validation with photographs confirmed the satellite-based observations of tidal flooding, mudflats, aquaculture, salt-affected lands, and intertidal zones, underscoring the dynamic and vulnerable nature of the Mahi estuary within the Gulf of Cambay coastal zone.

Conclusion

Different spatial classes are represented here in image for temporal resolution of 1978, 1990, 2000, 2011, 2017 along with the statistics and graphical bar charts on decadal scale. Followings are the conclusion:the climate, socio-economic condition has more influence on agriculture and settlements which has remained unchanged or marginally changed. Mangroves are taken care of by the nature. The contribution of water and sediments flux from river side is comparatively (based on referred research work) compare to mud flat expansion through tides within the gulf and along estuaries, encouraging more marine deposition and saline in nature. The quality degradation and quantity of mud flats in this region at the tail of Gulf is eye catching may excel prograding nature of shore line. The region is under fluvial marine deposition, but fluctuating contribution from river side, need more study on chemical analysis for refined work.

References

[1] Crossland Christopher J, Baird Dan, Ducrotoy Jean Paul A, Lindeboom H J:the domain of global interactions chapter-march 2006 https://www.researchgate.net/publication/226867603 [2] Carter R. W. G. 1988, coastal environments an introduction to the physical, ecological and cultural systems of coastlines\' academic press limited london. [3] WRI: World Resources Institute (2000): Revenga, C., Brunner, J., Henninger, N., Kassem, K., & Payne, R. freshwater systems. washington, dc.page,2000 world resources institute coastal ecosystem pilot anaysis of global ecosystem published by washington dchttp://www.wri.org/wr2000 [4] Crossland, C.J., Kremer, H.H., Lindeboom, H.J., Marshall Crossland, J.I., Le Tissier, M.D.A. (Eds.), 2005. coastal fluxes in the antropocene: the land–ocean [5] SAC: Space Applications Centre (ISRO), Ahmedabad (2012):coastal zones of india. isbn no. 978-81-90997b-9-b [6] [6]Niholls R J, Wong P.P., Burkett V, Codignotto,J. Hay, R. and others: coastal system and low lying area climate change 2007 4th assessment report of the ipcc uk cambridge university press 2007, 315-356 [7] CZI: 2012,coastal zone of india space applications centre (isro) ahmedabad isbn no. 978-81-90997b9b [8] Census of India, 2011, http://www.censusindia.gov.in/2011census/population_enumeration.html [9] GEC-2011 : Gujarat Ecology Commission Ecological : profile of coastal talukas around gulf of khambhat gandhinagar, 2011 [10] Shaikh M G; Nayak S ; Shah, P.N.; Jamusaria, B B. “Coastal Landform Mapping around the Gulf of Khambahat using Landsat TM data, Photonirvachak, Journal of the Indian Society of Remote sensing, Vol.17, No:1, 1989 [11] Turner R K and Adger W N (Lead Authors): coastal zone resources assessment guidelines, land-ocean interactions in the coastal zone (loicz), (igbp), (icsu) (cserge) research centre of the uk economic and social research council (esrc).1995 [12] Mahapatra, Manik Vulnerability of Gujarat coast due to sea level rise – an investigation based on remote sensing & GIS techniques , PhD Thesis, Nirma Univerity, Ahmedabad, Feb 2015. [13] Nina Siu-Ngan Lam, S. Liang (ed.), Methodologies for Mapping Land Cover/Land Use and its Change, Advances in Land Remote Sensing, 341–367. 341 c Springer Science + Business Media B.V., 2008 [14] Nayak, S. R and Sahai, B. (1985); Coastal morphology: a case study of the gulf of Khambhat (Cambay). Int. J. Remote Sensing, 1985, 6, 559–567 [15] Nayak Shailesh (2017) Coastal zone management in India ? present status and future needs, Geo-spatial Information Science, 20:2, 174-183, ISSN: 1009-5020 (Print) 1993-5153 (Online) [16] Desai P S, Narain A. Nayak S R. : IRS 1A: Applications for Coastal and Maine Resource, Current Science, Vol. 61, 3 & 4, 25 Aug’ 1991, Special Issue on: Remote sensing for National Development [17] Joshi, M D.; Sahai, Baldev: Mapping of salt-affected land in Saurastra coast using Landsat Satellite data, International Journal of Remote sensing, Vol:14, 1993, Issue: 10 [18] Nayak, S. & Bahuguna, A. Application of Remote sensing data to monitor mangroves and other coastal vegetation of India, Indian Journal of Marine Sciences, Vol 34, December 2001 [19] Chauhan, H. B., & Nayak, S. (2005). Land use/land cover changes near Hazira Region, Gujarat using remote sensing satellite data. Journal of the Indian society of Remote Sensing, 33(3), 413-420. [20] Misra, A. & Balaji, R. “Decadal changes in the land use/land cover and shoreline along the coastal districts of southern Gujarat, India, Environ Monit Assess (2015), Springer International Publishing Switzerland 2015 [21] Merh: S.S. Geology of Gujarat Geological Society of Gujarat Bangalore 1995 [22] Sourav saha, Anupam ghosh, Santanu Banerjee, Pratul k Saraswatiand Stuart D Burley. Characteristics of an Open Coast Tidal Flat: Example from Daman, West Coast of India, Journal geological society of India,2011 [23] Sourav Saha, Stuart D. Burley, Santanu Banerjee, Anupam Ghosh, Pratul K.Saraswati,; The morphology and evolution of tidal sand bodies in the macro tidal Gulf of Khambhat, Western India, 2015 [24] Modi D, Subhash Bhandari, 2018: Landscape change detection of Aliabet, Mouth of Narmada river, Gujart using geospatial tchniques, Journal of Emerging Technology and Innovative Research, Vol:5, Issue 7, ISSN: 2349-5162. [25] Merh S.S,(1995): Geology of Gujarat, Geological Society of India, Bangalore, 1995 [26] Patel M.P., Patel S.G. and Merh S.S.: Geomorphic studies on the Coastline between Mahi and Tapi river mouth paper published in Geology and Geomorphology of Quaternary Terrains of Gujarat with special reference to Coastline evolution: A report work of Dept. of Geology, M.S.University, December 1982 [27] Patel M.P., Patel S.G. and Merh S.S.: Geomorphic Evidences of Quaternary Sea-level changes in Mahi-Tapi coastal segment of Gujarat published in proceedings of the All-India Symposium, Geology Dept, M.S.University of Baroda, February 6-8, 1983 [28] Badrul Islam,Md Geological set up of the gulf of Khambhat Cambay A critical appraisal of the relevant onshore and offshore geo environmental parameters. Ph.D Thesis, Maharaja Sayajirao University of Baroda, 1986, Shodhganga. Web 16 December 2015. [29] Royer, A., Vincent, P., & Bonn, F. (1985). Evaluation and correction of viewing angle effects on satellite measurements of bidirectional reflectance. Photogrammetric Engineering and Remote Sensing, 51(12), 1899-1914.the process at regular time intervals. [30] Nayak S, Pandeya Anjali, Shaikh M G, Coastal Zone classification System: A Remote zone Classification system, Proceeding of the Seminar, National seminar on Quaternary Landscape of Indian Sub-Continent (1-3 December, 1988), M S University, Baroda, Gujarat (Proceeding 1991) [31] Shaikh M G; Shailesh Nayak; P.N.Shah, B B Jamusaria “Coastal Landform Mapping around the Gulf of Khambahat using Landsat TM data, Photonirvachak, Journal of the Indian Society of Remote sensing, Vol.17, No:1, 1989 [32] Ganpathi S, the Shoreline Morphology of the Gujarat Coast: An Appraisal, Status of Coastal zone studies and future trends: Special reference to western India , 24-25, Feb 2006, Dept. of Geology and SAC [33] WRIS,NRSC,2014: River basins of India GOI Ministry of water Resources CWC,NRSC, Sabarmati rive basin & Mahi river basin [34] Kunte, P. D. (2008). Sediment concentration and bed form structures of Gulf of Cambay from remote sensing. International Journal of Remote Sensing, 29(8), 2169-2182. [35] Deshkar S, Jayendra Lakhmapurkar: State of three estuaries of Gulf of Khambhat, Indian Journal of Geo-marine sciences, 2012 , 41(1): 70-75 [36] http://www.earthexplorer.usgs.gov/
