Design and Fabrication of CNC Thermocol Cutting Machine

Abstract

Traditional manual thermocol cutting often results in material waste and imprecise shapes. This project introduces a Thermocol Cutting Machine that uses a heated nichrome wire to cut thermocol (EPS) with high precision. Powered by an Arduino Uno, CNC shield, and stepper motors running GRBL firmware, it interprets G-code for smooth, accurate motion. The heated wire melts thermocol cleanly along the cutting path, producing burr-free edges. The machine supports complex patterns with minimal errors. Designed to be cost-effective and user-friendly, it suits industries, hobbyists, and educational use. This solution enhances cutting efficiency and reduces manual effort.

Introduction

Plastic products, especially plastic foam, are widely used in daily life. Plastic foam is commonly manufactured by casting or extrusion, and hotwire cutting is an effective method to shape these foams. Hotwire cutting uses a heated wire that melts the foam along the cutting path, allowing smooth, low-force cutting.

There are three main cutting mechanisms for plastic foam:

• Thermal cutting: foam melts or vaporizes just ahead of the wire without contact.

• Thermo-mechanical cutting: combines shearing force with melting, with the heated tool in contact.

• Mechanical cutting: relies on shearing without melting, when tool temperature is below foam’s melting point.

The cutting wire heats up due to electrical resistance, melting the foam it contacts and creating smooth cuts. The quality of the cut depends on wire diameter and cutting speed.

Literature Review

Many researchers have studied parameters affecting polymer foam cutting, such as material removal rate, kerf width (cut width), surface roughness, wire temperature, feed rate, and cutting angle. Various models and experimental setups—including CNC and robotic hotwire cutters—have been developed to optimize cutting quality and precision, especially for expanded polystyrene (EPS) foam.

Software and CNC Machine Operation

• GRBL firmware and Universal G-code Sender software are used to control the CNC hotwire cutter by sending G-code instructions to an Arduino board.

• Designs are created in CAD software and converted to G-code using vector graphic tools like Inkscape.

• The CNC machine follows programmed wire paths, heating the wire to melt foam precisely along the design.

Working Principle

The CNC hotwire foam cutter melts and cuts foam into shapes via a heated wire guided by computer-controlled motors. The process involves:

• Designing the shape in CAD software.

• Preparing foam and setting wire tension and temperature.

• Initializing and calibrating the CNC machine.

• Executing the cut by following the programmed tool path.

• Inspecting and finishing the cut piece for quality.

In essence, the hotwire CNC foam cutter efficiently produces precise foam shapes by combining electrical heating, CNC control, and optimized cutting parameters.

Conclusion

1) The hot wire CNC foam cutting machine is an excellent tool for a precise and efficient way of cutting foam material. This tool integrates heated wire movements controlled by a computer to perform accurate and intricate cuts on foam blocks or sheets. 2) The CNC hot wire foam cutting machine processes cuttings in an automated manner and hence the productivity level is very much increased while manual labor is reduced. The machine cuts complicated shapes and designs with high precision and thus ensures constant cutting results. It also has flexibility concerning customized cutting with respect to foam thicknesses and densities. 3) The different considerations required while selecting and assembling the key components of the machine such as the frame, stepper motors, hot wire system, control electronics, and so on must be deliberated upon throughout the project. The cutting paths designed for the machine must be programmed. 4) The safety measures implemented should guarantee safety to operators and safe operation of the machine. The machine must be maintained periodically with a calibration routine to enhance its performance and accuracy. Hot wire CNC foam cutting machines are widely adopted in many industries, including packaging, insulation, model making, signage, etc.; making it an economical option for the precision production of foam parts. In summary, the hot wire CNC foam cutting machine is by far a great asset for the foam industry; properly assembled, programmed, and maintained-fine cutting operation in many industries. The machine offers precise cutting, automation, versatility, and customizing options.

References

[1] Aitchison, D., Brooks, H., Bain., J., Pons, D. “An Investigation into the Prediction of optimal Machining Conditions for Polystyrene Foam Cut with a Taut Hot-Wire”. The Annals of “Dunarea de Jos” University of Galati, Fascicle V, Technologies in Machine Building, ISSN 1221- 4566, 2009 [2] H. Brooks, “Plastic Foam Cutting Mechanics for Rapid Prototyping and Manufacturing Purposes” (Ph.DThesis), Mechanical Engineeringat the University of Canterbury , Christ church , New Zealand , 2009 [3] Harmanpreet & Manpreet Singh, “Influence on Kerf Width in Machining Polystyrene by Heating Element Profile Maker using Nichrome Wire”, International Journal of Engineering and Technical Research V4 (04), April 2015 [4] Ranjeet K. B., Sajan K., Pushkar K. &K. P. Karunakaran , “Investigation of ablation studies of EPS pattern produced by rapid prototyping”, Virtual and Physical Prototyping, Volume 13, Issue 4, 2018. [5] Kiril P.Petkov, Jesper H.Hattel” A thermo-electro-mechanical simulation model for hot wire cutting of EPS foam” International Journal of Machine Tools and ManufactureVolume 107, Pages 50-59,2016. [6] Namrata Karmakar , Sathyan Subbiah , “Investigating Bowing of Hot Wire during cutting of EPS” Procedia Manufacturing Volume 26, Pages 671-680, 2018 [7] Luka Ivanovskis, “Four Axis Hot-Wire Foam Cutter Controlled by Mind storms EV3 “, Saimaa University of Applied Sciences, Faculty of Technology, Lappeenranta Degree Programme in Mechanical Engineering and Production Technology, Thesis 2017 [8] Dong-Gyu Ahn, Sang-Ho Lee, Dong-Yol Yang, “Influence of process parameters on the surface roughness in hotwire cutting ofEPS foam sheet for VLM-S rapid prototyping process”, Journal of Materials Science 40(21):5699-5702, 2005 [9] P. Gallina, R. Mosca, P. Pascutto, “Optimized Hotwire Cutting Robotic System for Expandable Polystyrene Foam”, AMST’05 Advanced Manufacturing Systems and Technology. CISM International Centre for Mechanical Sciences, vol 486. Springer, Vienna, 2005 [10] Katrine Sivertsen, polymer foams,3.063 Polymer Physics, Spring2007 [11] https://libraries.io/github/winder/Universal-G-Code-Sender [12] R. K. Roy,” Aprimer on the Taguchi method”,1ST Edition (New york: Van Nostrand Reinhold ,1990) [13] BalaRaju.J, Anup Kumar.J, Dayal Saran.P, Dr.C.S.Krishna Prasad Rao\"Application of Taguchi Technique for Identifying Optimum Surface Roughness in CNC end Milling Process\", International Journal of Engineering Trends and Technology (IJETT), V21(2),103-110 March 2015. [14] M.Vishnu Vardhan, G. Sankaraiah, M. Yohan , H. Jeevan Rao , ”Optimization of Parameters in CNC milling of P20 steel using Response Surface methodology and Taguchi Method” ,Science Direct ,Volume 4, Issue 8, , Pages 9163-9169 ,2017. [15] Shouvik Ghosh, Prasanta Sahoo, and Goutam Sutradhar, “Tribological Performance Optimization of Al-7.5% SiCp Composites Using the Taguchi Method and Grey Relational Analysis”, Journal of Composites, Volume, Article ID 274527, 2013 [16] Hanan H. Murad, “Parametric Investigation of the Magnetic Abrasive Finishing Method” (MS.c Thesis), Al-Khwarizmi College of Engineering of University of Baghdad, 2017 [17] Marwa K. Qate’a, Ali H. kadhum, Faiz F. Mustafa, “The Influence of the Magnetic Abrasive Finishing System for Cylindrical Surfaces on the Surface Roughness and MRR “ , Al-Khwarizmi Engineering Journal, Vol 11 No 3 , 2015
