IOT Integrated Transformer Health Monitoring and Predictive Maintenance System

Abstract

Power distribution networks depend heavily on transformers, and their failure can seriously interrupt operations. In order to track transformer health and forecast maintenance requirements, this study presents a smart system that integrates IoT technologies. It makes defect detection and condition assessment possible in real time. The system uses a variety of sensors to track important metrics like voltage, current, power, energy, frequency, power factor, and temperature. Data is sent wirelessly through an ESP8266 to the ThingSpeak cloud, where it’s analyzed for any irregularities. A machine learning model, trained on historical sensor data, helps predict potential faults by using set thresholds, which aids in early detection and preventive maintenance. To make it even better, the system features a user-friendly dashboard built with Streamlit that offers real-time monitoring, fault classification, and instant alerts. It also explores different communication technologies like GSM, LoRa, Zigbee, and Bluetooth to ensure reliable data transmission. The Random Forest model achieves an impressive 99.2% classification accuracy, demonstrating the system\'s remarkable fault prediction accuracy. This method reduces maintenance costs, increases transformer dependability, and helps avoid power outages by combining IoT, cloud computing, and AI analytics. In the future, three-phase industrial transformers may benefit from improved scalability and faster fault detection with the integration of edge computing.

Introduction

Overview:
Transformers are critical in power grids, but 70–80% of failures result from internal issues like overheating and insulation breakdown. Traditional maintenance methods, such as periodic inspections, lack real-time fault detection. Modern Transformer Health Monitoring Systems (THMS) using IoT sensors and AI analytics enable early issue detection, improving safety, reliability, and transformer lifespan.

Prototype Development:

• Purpose: A scaled-down prototype was developed as a proof-of-concept to simulate real transformer environments. It integrates AI-based fault detection, sensor monitoring, and an interactive UI for proactive maintenance.

• Scalability: Though built for a single-phase transformer, the methodology is scalable to three-phase industrial systems.

• Phase-Level Monitoring: Detects specific faults (overload, underload, temperature shifts) using machine learning on real-time data.

Literature Review Highlights:

• Past studies explored various IoT platforms, sensors, and communication methods (e.g., GSM, Wi-Fi, ThingSpeak).

• Limitations included:

  • No AI-driven predictive maintenance

  • Focus on threshold-based alerts

  • Inadequate scalability and network stability in remote areas

• This research addresses these gaps by integrating ML prediction, IoT, and robust cloud platforms.

System Methodology:

1. Hardware Module:

• Uses sensors to measure voltage, current, power, frequency, power factor, and temperature.

• Data is sent via ESP8266 microcontroller to the cloud every 30 seconds.

• A load variation setup simulates real-world transformer stress.

• LCD displays real-time values on-site.

2. Cloud Platform (ThingSpeak):

• Stores and visualizes real-time sensor data.

• Enables remote monitoring, data analysis, and fault tracking.

• Supports historical trend analysis and comparison with real transformer values.

3. Machine Learning Model:

• Random Forest achieved 99.2% accuracy in fault detection.

• Trained with real sensor data for predicting:

  • Overheating & Overvoltage

  • Overvoltage

  • Undervoltage

  • Normal Operation

• Uses Pickle/Joblib for deployment.

• Hosted on GitHub for accessibility and future updates.

4. User Dashboard & Interface:

• Displays real-time transformer health data.

• Allows for intuitive monitoring and alert response.

Conclusion

This paper presents an IoT-integrated transformer health monitoring and predictive maintenance system, leveraging advanced communication technologies such as GSM, LoRa, Zigbee, and Bluetooth to enable real-time condition assessment. By incorporating multi-sensor fusion and AI-driven predictive analytics, the proposed system enhances fault detection, reduces downtime, and extends transformer lifespan. The reviewed studies highlight the effectiveness of IoT in improving reliability, efficiency, and automation in power distribution networks. Future work can focus on integrating edge computing and machine learning for further optimization, ensuring a more resilient and intelligent power grid.

References

[1] A. Patel and R. Sharma, \"Real-time transformer health monitoring using GSM technology,\" International Journal of Electrical Engineering, 25(3), 45–52 (2018). [2] R. R. Pawar and S. B. Deosarka, “Health condition monitoring system for distribution transformer using Internet of Things (IoT),” IEEE, 978-1-5090-4890-8/17 (2017). [3] H. Jamal, M. F. N. Khan, A. Anjum, and M. K. Janjua, “Thermal monitoring and protection for distribution transformer under residential loading using Internet of Things,” IEEE, 978-1-5386-8509-9 (2018). [4] J. D., S. Khandai, and N. K. Roy, “IoT-enabled smart condition monitoring tool for oil-filled transformers,” International Journal of Intelligent Systems and Applications in Engineering (2023). [5] S. Shitole, N. Shaikh, P. Patil, and R. Mithari, “IoT-based transformer monitoring system,” International Research Journal of Modernization in Engineering Technology and Science, 4(5), May 2022. [6] P. R., C. N., S. S. Bhagyalakshmi, and D. A., “Design and implementation of real-time transformer health monitoring system using Raspberry Pi,” IJERT, Issue 2018, ISSN: 2278-0181 (2018). [7] L. Chen, H. Wu, and J. Zhang, \"Edge computing and LoRa integration for real-time transformer fault detection,\" IEEE Transactions on Industrial Informatics, 19(1), 156–167 (2023). [8] A. Ali, M. Khan, and L. Zhao, \"Artificial intelligence for predictive maintenance in GSM and LoRa-based transformer monitoring,\" Journal of Smart Grid Technologies, 15(1), 112–125 (2022). [9] Y. Zhang, X. Li, and H. Wang, \"IoT-enabled multi-sensor fusion for intelligent transformer monitoring,\" IEEE Internet of Things Journal, 8(7), 5456–5467 (2021). [10] S. Prasad, N. Mehta, and V. Reddy, \"Hybrid GSM and Bluetooth-based transformer monitoring system,\" International Journal of Electrical and Electronics Research, 14(2), 189–198 (2020). [11] P. Singh and A. Verma, \"Application of LoRa technology for smart transformer monitoring,\" Renewable Energy and Smart Grid Journal, 10(2), 78–89 (2020). [12] R. Kumar, M. Jain, and P. Singh, \"Zigbee-based wireless sensor network for transformer monitoring,\" IEEE Transactions on Power Electronics, 34(5), 1234–1242 (2019). [13] B. Wang, J. Liu, and C. Chen, \"A comparative study of Zigbee and LoRa for transformer health monitoring,\" IEEE Wireless Communications Letters, 8(9), 2456–2461 (2019). [14] T. K. Roy, “Implementation of IoT: Smart maintenance for distribution transformer using MQTT,” IEEE, 978-1-5386-4775-2 (2018). [15] M. S. Naderi and O. Abedinia, “Transformer active part fault assessment using Internet of Things,” IEEE, 978-1-5386-5928-1 (2018).M. Rahman, T. Alam, and S. Roy, \"Bluetooth-based diagnostic system for power transformers,\" International Journal of Electrical and Computer Engineering, 7(4), 295–302 (2017). [16] S. Rahman and N. K. Das, “Design and implementation of real-time transformer health monitoring system using GSM technology,” IEEE, 978-1-5090-5627-9 (2017). [17] S. Gupta and K. Rao, \"GSM-based alert system for transformer fault detection,\" Power Systems and Control Engineering Journal, 12(3), 88–97 (2016). [18] A. Nelson, G. Makarand, D. R. Tutakne, C. Jaiswal, and S. Ballal, “Remote condition monitoring system for distribution transformer,” IEEE, 978-1-4799-5141-3/14 (2014). [19] S. H. Mohamadi and A. Akbari, “A new method for monitoring distribution transformer,” IEEE, 978-1-4577-1829-8 (2012). [20] H. Mao, “Research of Wireless Monitoring System in Power Distribution Transformer Station Based on GPRS,” IEEE, 5, 978-1-4244-5586-7/10 (2010). [21] J. Crossey and W. Ferguson, “On-line monitoring and diagnostics for power transformers,” IEEE, 978-1-4244-6301-5 (2010).
