Design, Development and Manufacture of 7.3 metre Full Motion Tri- band Antenna for Remote Sensing Applications (S,X,Ka band)

Abstract

The increasing demand for high-resolution, real-time data in remote sensing applications has driven advancements in antenna technology, particularly in the design of large, full-motion systems capable of tracking and communicating with satellites across diverse orbits. This project focuses on the design, development, and manufacture of a 7.3-meter full-motion antenna tailored for remote sensing applications, addressing the need for precision, durability, and adaptability in challenging operational environments. The antenna system is engineered to support a wide range of frequencies, provide high gain, and maintain tracking accuracy under dynamic conditions, making it a critical asset for applications such as environmental monitoring, disaster management, and scientific research.

Introduction

Remote sensing antennas, particularly full motion types, are vital for modern scientific and technological applications including satellite communication, earth observation, weather monitoring, and space exploration. The 7.3-meter full motion antenna project focuses on designing, simulating, prototyping, testing, and producing a high-precision antenna capable of operating across multiple frequency bands (S, X, and Ka bands). This antenna features a parabolic reflector with dual-axis motion control for accurate tracking of satellites and other targets, supporting diverse applications from environmental monitoring and disaster management to defense communications.

The literature review highlights existing full motion antennas, noting a trade-off between size, agility, and frequency versatility. The 7.3-meter antenna aims to balance these factors with advanced materials, multi-band feed systems, and improved motion control to enhance performance. Key system requirements include triband capability, bidirectional communication, automation, and maintainability.

Design choices favor lightweight aluminum alloys for the reflector and steel for structural support to balance durability and weight. Applications cover earth observation (soil, water, urban planning), weather forecasting, and space communication, leveraging the strengths of each frequency band. Technical challenges include integrating triband operation, ensuring precise and rapid full-motion tracking, mitigating signal loss in the Ka-band due to weather, and managing thermal effects to maintain antenna stability and performance.

Conclusion

The primary objective of this project was to design, develop, and manufacture a 7.3-Meter full-motion antenna capable of operating across the S, X, and Ka frequency bands, tailored specifically for remote sensing applications. This ambitious goal was successfully achieved through a systematic approach encompassing theoretical design, simulation, prototyping, and manufacturing phases. The antenna system was engineered to meet stringent performance requirements, including high gain, precise tracking, and operational reliability under diverse environmental conditions. The development of the 7.3-Meter full-motion triband antenna represents a noteworthy contribution to the field of remote sensing technology. One of the most significant advancements is the enhancement of multi-frequency capabilities within a single antenna platform. Traditionally, remote sensing missions have relied on separate antennas for different frequency bands, leading to increased costs, complexity, and logistical challenges. By integrating S, X, and Ka-band operations into one system, this project offers a cost-effective and versatile solution that can support a broad spectrum of applications, including meteorological data collection, synthetic aperture radar (SAR) imaging, and high-resolution earth observation. While this project has achieved its core objectives, several avenues for improvement and expansion remain open for future exploration. These recommendations aim to enhance the antenna’s capabilities, broaden its applications, and address potential limitations identified during the research.

References

[1] Balanis, C. A. (2016). Antenna Theory: Analysis and Design (4th ed.). Wiley. • A foundational text for antenna design principles, including reflector and feed systems. [2] Milligan, T. A. (2005). Modern Antenna Design (2nd ed.). Wiley-IEEE Press. • Covers practical aspects of designing large reflector antennas for multi-band operation. [3] Skolnik, M. I. (2008). Radar Handbook (3rd ed.). McGraw-Hill. • Provides insights into X-band radar systems and their remote sensing applications. [4] Richards, M. A., Scheer, J. A., & Holm, W. A. (2010). Principles of Modern Radar: Basic Principles. SciTech Publishing. • Discusses S-band and Ka-band radar systems for atmospheric remote sensing. [5] Pozar, D. M. (2011). Microwave Engineering (4th ed.). Wiley. • Essential for understanding microwave feed systems and RF performance analysis. [6] Johnson, R. C., & Jasik, H. (1984). Antenna Engineering Handbook (2nd ed.). McGraw-Hill. • A comprehensive resource on large antenna structures and motion mechanisms. [7] IEEE Standard for Definitions of Terms for Antennas (IEEE Std 145-2013). (2013). IEEE. • Standard terminology and metrics for antenna performance evaluation. [8] Kraus, J. D., & Marhefka, R. J. (2002). Antennas for All Applications (3rd ed.). McGraw-Hill. • Includes design considerations for parabolic reflectors and multi-frequency systems. [9] Stutzman, W. L., & Thiele, G. A. (2012). Antenna Theory and Design (3rd ed.). Wiley. • Offers advanced topics on antenna gain and beamwidth optimization. [10] Gao, S., Luo, Q., & Zhu, F. (2014). Circularly Polarized Antennas. Wiley-IEEE Press. • Relevant for polarization design in triband systems. [11] Bhartia, P., Rao, K. V. S., & Tomar, R. S. (1991). Millimeter-Wave Microstrip and Printed Circuit Antennas. Artech House. • Focuses on Ka-band antenna design and fabrication techniques. [12] Ulaby, F. T., Moore, R. K., & Fung, A. K. (1981). Microwave Remote Sensing: Active and Passive (Vol. 1). Artech House. • A classic text on remote sensing principles and antenna requirements. [13] Mailloux, R. J. (2005). Phased Array Antenna Handbook (2nd ed.). Artech House. • Useful for understanding feed system alternatives for triband operation. [14] Hansen, R. C. (2009). Microwave Scanning Antennas. Peninsula Publishing. • Discusses full-motion mechanisms and tracking systems for large antennas. [15] Silver, S. (1984). Microwave Antenna Theory and Design. IET. • Historical perspective on reflector antenna design and manufacturing. [16] Collin, R. E. (1985). Antennas and Radiowave Propagation. McGraw-Hill. • Covers wave propagation and antenna performance in remote sensing contexts. [17] IEEE Transactions on Antennas and Propagation. (Various Issues, 2015–2023). IEEE. • Peer-reviewed articles on recent advancements in multi-band antenna systems. [18] Rappaport, T. S. (1996). Wireless Communications: Principles and Practice. Prentice Hall. • Background on frequency band applications in communication and sensing. [19] Chahat, N. (Ed.). (2021). CubeSat Antenna Design. Wiley-IEEE Press. • Modern reference for compact feed systems adaptable to larger antennas. [20] Toomay, J. C., & Hannen, P. J. (2004). Radar Principles for the Non-Specialist (3rd ed.). SciTech Publishing. • Simplified explanation of radar and antenna systems for remote sensing. [21] Updated Antesky 7.3m full motion tri band antenna [22] Material Select and design for 7.3 m dual band antenna [23] Astronomical Techniques and instruments • Block diagram of the servo control system [24] Researchgate.net • A correction method of estimating the pointing error for reflector antenna [25] SpaceOps Conferences, 28 May - 1 June 2018, Marseille, France 2018 SpaceOps Conference A.Karas(1), P.Cousin(1), G.Kipfer(1), A.Robert(1) • A Triband Autotrack concentric Feed S, X, Ka for Ground Stations related to Earth Observation [26] Researchgate.net • DC servomotor based antenna positioning control system design using hybrid PID-LQR controller [27] Electronics Desk • Satellite Uplink and Downlink in communication satellites [28] Researchgate.net • Satellite tracking system by P. Ushasree, S. Sahithi, T. Anjali Shivani Reddy under guidance of Dr. S. Ramani and Dr. A. N. Satyanarayana at NRSC, ISRO. [29] Researchgate.net • Modelling and Stabilization of Three - Axis – Ship mounted mobile antenna system by Ibrahim sina kuseyri, Marmara University.
