Ornithology-Inspired Flow Analysis for Optimized Artificial Mellisuga Helenae Performance

Abstract

An remarkable effectiveness of actual bird flight, this project\'s aim is to develop a biomimetic artificial Mellisuga Helenae featuring a semi-elliptical wing design. The aim is to develop unmanned aerial vehicles (UAVs)capableofexecutingvarious efficient tasksin areas like wildlife monitoring, ecological assessment, and emergency response bymimickingbasicflightdynamics such as flapping, folding, and bending. The wing design, incorporating camber and twist, wasmeticulouslycraftedwithadvancedCAD software such as SolidWorks to enhance lift and maintain precise control during flight.

Introduction

Objective

The project aims to design an artificial bird wing, specifically mimicking the Mellisuga Helenae (the world’s smallest bird), and to simulate its aerodynamic and structural performance. The goal is to develop a flapping and folding wing mechanism for use in biomimetic unmanned aerial vehicles (UAVs), or ornithopters, which are useful in challenging environments for tasks like disaster relief and wildlife monitoring.

Design Focus

• Wing Motion Types: Flapping, folding, bending, twisting – focus is on Flapping & Folding Motion (FFM).

• Mechanism: Uses a 4-bar linkage to model wing movements.

• Wing Shape: Semi-elliptical for reduced drag and enhanced lift.

• Wing Geometry: Incorporates biologically inspired features (twist, camber) using CAD tools like SolidWorks.

Key Design Parameters

• Aspect Ratio & Span: Designed for maneuverability in tight spaces.

• Wing Loading: Ensures the structure can withstand forces during flight.

• Low-speed Airfoils: Uses profiles like S1223 or Eppler E423 suitable for low-Reynolds-number flight.

Methodology

1. CAD Modeling: Detailed 3D modeling of the wing and structure.

2. Simulation Tools:

   • CFD (Computational Fluid Dynamics) for airflow, lift, and drag analysis.

   • Structural Simulation for stress and deformation checks.

3. Testing & Validation: Prototypes tested in wind tunnels and real conditions to refine the design.

Challenges Addressed

• Lightweight design without sacrificing strength.

• Energy efficiency during flapping.

• Fatigue resistance of materials.

Simulation & Analysis

• Pressure & Velocity Fields: Analyzed around the ornithopter to understand aerodynamic behavior.

• CFD Results: Show regions of high/low velocity and pressure, helping optimize wing design.

Design Output

• Includes dimensioned sketches, 3D models, and isometric views.

• Illustrates structural components like spars, ribs, and mechanical joints.

• Final prototype validated through simulated and physical testing.

Conclusion

With the successful conception, design, and analysis of a lightweight artificial bird with a semi-elliptical wing structure, we have made a significant advancement in the field of biomimetic design and aeronautical engineering and have taken a decisive step toward incorporating nature\'s flight dynamics into contemporary unmanned aerial vehicles (UAVs). This work demonstrates the potential of biomimetic solutions to address a variety of challenges, from disaster management to environmental conservation, by simulating the effectiveness, agility, and adaptability of natural flyers. This study\'s selection and optimization of a semi-elliptical wing design was one of its key achievements; its demonstrated aerodynamic efficiency, which is characterized by fewer wingtip vortices and an even distribution of lift, gave the artificial bird a strong basis for performance, and advanced computational fluid dynamics (CFD) simulations and material optimization ensured that the wing could withstand a variety of aerodynamic forces while maintaining a lightweight and durable structure.

References

[1] Seung Wan Ryu, Jong Gu Lee, Hyoun Jin Kim(2020).Design, Fabrication, and Analysis of Flapping and Folding Wing Mechanism for a Robotic Bird, https://doi.org/10.1007/s42235-020-0018-3 [2] Suyang Qina,Wengb, Zhuoqi Lia,Yang Xianga,Hong Liua(2021). On the controlled evolution for wingtip vortices of a flapping wing model at bird scale, www.elsevier.com/locate/aescte [3] R Yousaf , A Shahzad , MN Mumtaz Qadri and A Javed(2020). Recent advancements in flapping mechanism and wing design of micro aerial vehicles. Recent advancements in flapping mechanism and wing design of micro aerial vehicles - R Yousaf, A Shahzad, MN Mumtaz Qadri, A Javed, 2021 [4] Janusz,Cwiklak , Ewelina Kobia?ka and Artur Go´s(2022). Experimental and Numerical Investigations of Bird Models for Bird Strike Analysis. Energies 2022, 15,3699. https://doi.org/10.3390/en15103699 [5] Marc May, Gertjan Looye, Daniel Milz,(2023). Semi-Empirical Aerodynamic Modeling Approach for Tandem Tilt-Wing eVTOL Control Design Applications. https://www.researchgate.net/publication/366338502 [6] Tarun Golla, Adithya Muralikrishna, Sundaram Thirukkurungudi(2020). Analyzing Surface Textures on Elliptical Wings A CFD Analysis of Stall Angles at High Angles of Attack. http://www.ijert.org [7] Swathi Krishna , Moonsung Cho, Henja-Niniane Wehmann, Thomas Engels and Fritz-Olaf Lehmann,(2020). Wing Design in Flies: Properties and Aerodynamic Function. Insects 2020, 11, 466. www.mdpi.com/journal/insects [8] Marcello,Righi1,Marco,Breech(2019). On Elliptical Wings in Subsonic Flow: Indicial Lift Generation via CFD Simulations – with Parametric Analytical Approximations.[2001.06734] On Elliptical Wings in Subsonic Flow: Indicial Lift Generation via CFD Simulations -- with Parametric Analytical Approximations [9] M A Moelyadi1, E Amalia1,A D Tanoto1, L M Septiani1,M Rafie2,A S Perdana1 and R Agung1(2020). Preliminary design of bionic flapping wing vehicle.Preliminary design of bionic flapping wing vehicle - IOPscience [10] Ariel Drachinsky,Daniella E. Raveh, Moshe Tur(2022). Experimental Aeroelastic Benchmark of a Very Flexible Wing. https://doi.org/10.2514/1.J060621 [11] Hamid Isakhani 1, Nicola Bellotto 1, Qinbing Fu1,2 and Shigang Yue1,2(2021). Generative design and fabrication of a locust-inspired gliding wing prototype for micro aerial robots. http://orcid.org/0000-0002-7443-371X [12] Seung Wan Ryu, Jong Gu Lee, Hyoun Jin Kim(2020). Design, Fabrication, and Analysis of Flapping and Folding Wing Mechanism for a Robotic Bird. http://www.springer.com/journal/42235 [13] Satrudhan Kumar Sah ,Sumit Pramanik (2022). Design and development of mechanical bird. https://doi.org/10.1063/5.0096110 [14] Kushal Jadhav, Harshada Javheri, Nikita Durge, Akash Hange, Asst. Prof. Rohit R. Chavan(2020). Design, Development and Analysis of Ornithopters. Engineering Research Volume 11, Issue 7, July-2020. http://www.ijser.org [15] Srikar Kavuri ,Siva Sudhamsu,Anish Sesham(2022). Lift estimation and comparison of ornithopter of different wing materials and wing shapes. [16] Akshayraj N, Shreya M, Sujan D Silva, Vrishab S M, Shilpa N R(2021). Design and Development of an Ornithopter by Aerodynamic and Structural Analysis. http://creativecommons.org/licenses/by/4.0 [17] J.V. Caetanoa, M. Percinb, B. W. van Oudheusdenb, B. Remesb, C. de Wagterb, G.C.H.E. de Croonb, C.C de Visserb(2015). Error Analysis and Assessment of Unsteady Forces Acting on a Flapping WingMicro Air Vehicle: Free-Flight versus Wind Tunnel Experimental Methods. http://dx.doi.org/10.1088/1748-3190/10/5/056004 [18] Adedotun Adetunla1, Bernard Adaramola1,abeebullah Abdulkadir2(2023). Advancements in the Design and Automation of Biomimetic Ornithopters: An Investigation into Flapping-Wing Flight Control. https://doi.org/10.56578/jisc020204 [19] Erzhen Pan1, Lianrui Chen1, Bing Zhang1, and Wenfu Xu1,2(2017). A Kind of Large-Sized Flapping Wing Robotic Bird: Design and Experiments. wfxu@hit.edu.cn [20] Rishabh Goel , Tien Pham , Phuc Nguyen Josiah Hester(2023). Exploring Batteryless UAVs by Mimicking Bird Flight. https://doi.org/10.1145/3597060.3597243
