Design and Performance of Grey Water Treatment Plant

Abstract

Advanced Oxidation Processes (AOPs), Moving Bed Biofilm Reactor (MBBR) systems, and Constructed Wetlands (CWs) to enhance efficiency of organic and inorganic pollutant removal. MBBR system consists of an aeration tank it is similar to a activated sludge tank with plastic media which surface biofilm can grow. Initially grey water feed to AOP system then MBBR and finally pass through wetland construction. AOP and MBBR is a recent and beneficial biofilm technology which has many properties which includes anti-load ability, High treatment efficiency. AOP and MBBR technology became more popular and widely utilized worldwide due to fact that need for clean water keeps to rapidly increase with increase in population of the world grows year by year. Greywater from Bathroom Water used in hand washing and bathing generates around 50-60% of total greywater and is considered to be the least contaminated type of greywater. Greywater is specifically washing water like bath, dish and laundry water excluding toilet wastes and free of garbage-grinder residues. Gray water shows the Initial characteristics TDS, pH and SS are 900 mg/l, 8.5 and 413 mg/l. After treating with AOP shows the TDS, pH and SS are 750 mg/l, 8.3 and 327 mg/l, after MBBR treatment TDS, pH and SS are 400 mg/l, 8.3 and 104 mg/l and Final wet land construction treatment TDS, pH and SS are 118 mg/l, 8.3 and 50 mg/l.

Introduction

1. Introduction to Greywater

• Greywater refers to wastewater from baths, laundry, and sinks—excluding toilet waste.

• It is considered a potential resource for irrigation in agriculture and landscaping.

• If untreated, greywater can pollute water bodies but is also rich in nutrients beneficial for vegetation.

2. MBBR Technology

• Moving Bed Biofilm Reactor (MBBR) is an efficient biological treatment process.

• Invented in the 1980s, MBBR uses an aeration tank with plastic media to support microbial growth.

• Widely adopted in over 50 countries, it is now used in municipal and industrial systems.

3. Greywater Composition

• Bathroom greywater: 50–60% of total greywater; contains soaps, shampoos, and pathogens.

• Laundry greywater: 25–35%; includes detergents and fabric residues.

4. Experimental Setup

• Raw Materials: Greywater sample, MBBR media, H?O?, acids/alkalis.

• Apparatus: Aeration pump, bioreactor tanks, measuring instruments.

• Procedure: Greywater passes through three treatment stages:

  1. AOP (Advanced Oxidation Process)

  2. MBBR Biological Treatment

  3. Wetland Filtration

5. Results and Discussion

• Initial water quality:

  • TDS: 900 mg/L

  • pH: 8.5

  • SS: 413 mg/L

• Post-treatment values:

  • After AOP: TDS 750 mg/L, SS 327 mg/L

  • After MBBR: TDS 400 mg/L, SS 104 mg/L

  • After Wetland: TDS 118 mg/L, SS 50 mg/L

• Overall reduction:

  • TDS reduced by 86.88%

  • SS reduced by 87.89%

6. Observations

• Treatment efficiency improves with increased contact time (3, 6, 9 hours).

• MBBR significantly reduces organic and suspended solids.

• The final wetland stage acts as a polishing filter, further reducing pollutants.

7. Graphical Analysis

• Graphs illustrate the progressive reduction in TDS and SS across the three treatment stages:

  • AOP: Initial drop

  • MBBR: Major reduction

  • Wetland: Final refinement

Conclusion

Greywater is specifically wash water like bath, dish and laundry water excluding toilet wastes and free of garbage-grinder residues. MBBR technology became more popular and widely utilized worldwide due to fact that need for clean water keeps to rapidly increase with increase in population of the world grows year by year. the % reduction of TDS and SS from gray water using AOP, MBBR and wetland construction treatment. Graph shows the % reduction in TDS and SS using AOP, MBBR and wetland construction treatment are 16.66%, 55.55%, 86.66% and 20.82%, 74.81%, 87.89% resp.

References

[1] Akhin George, Ancy C J, Anupama Renjini K R, Jithin P Nair and Jency Nadayil, Characterization of Grey Water and Treatment using Moving Bed Biofilm Reactor (MBBR), International Research Journal of Engineering and Technology (IRJET) e-ISSN: 2395-0056 Volume: 06, Issue: 04, Apr 2019. [2] AhmadMajid, MehrazaranMahna, Application of Lab-Scale MBBR to Treat Industrial Wastewater using K-3 Carriers: Effects of HRT, High COD Influent and Temperature, International Journal of Environmental Sciences & Natural Resources Volume 20 Issue 2 - June 2019. [3] Bavor Herbert John and Michael Waters, Pollutant transformation performance in a peri-urban African wetland system receiving point source effluent and diffuse source pollutant inputs, Ecohydrol. Hydrobiol ,7 (3-4), 201-206, 2007. [4] Gross A., O. Shmueli, Z. Ronen and E. Raveh, Recycled vertical flow constructed wetland (RVFCW)—a novel method of recycling greywater for irrigation in small communities and households, Elsevier, Chemosphere 66, 916–923, 2007. [5] Heenalisha K. and R. Prashanna Rangan, Grey-Water Treatment and Reuse: A Review, Asian Journal of Science and Applied Technology, ISSN: 2249-0698 Vol. 8 (1), pp. 5-9, 2019. [6] Hanna Porsgaard and Sofia Söderström, Removal of Nitrogen from Landfill Leachates with MBBR and SBR A Pilot Study at the Brudaremossen Landfill, Chalmers University of Technology, Gothenburg, Sweden 2015. [7] Mariana Chrispima, Marcelo AntunesNolasco, André Santosc, Gabriel Inacio Silva-Netod, Neildes Souza Santana Water Resources Saving: A Possibly Contribution from a Greywater Collection, Treatment and Reuse, Conference on International Research on Food Security, Natural Resource Management and Rural Development, 2014. [8] Mr. Lambe J. S. and R. S. Chougule, Greywater Treatment and Reuse, Department of Civil Engineering, D.J. Magdum College of Engineering, Jaysingpur, IOSR Journal of Mechanical and Civil Engineering (IOSR-JMCE) ISSN: 2278-1684, PP: 20-26, 2018. [9] Mohammad JavadAmiri and Mehdi Bahrami, Clustering the Adsorbents of Horizontal Series Filtration in Greywater Treatment, Sustainability, 12, 3194, 2020. [10] MohantyBibhabasu&Zeel Patel, Use of Natural Materials for Low Cost and Effective Technology for Greywater Treatment, Science, Technology and Development, Volume VIII, Issue XI, November, ISSN: 0950-0707, 2019. [11] Mr. Kazi Faraz Ahmed Abdullah1, Prof. D. C. Poul, Prof. S. C. Vadane and Prof. P.A., Hangargekar MBBR Treatment for Purification of Grey Water in Venkateswara Greens Society, International Research Journal of Engineering and Technology (IRJET), ISSN: 2395-0056, Volume: 09, Issue: 04, Apr 2022. [12] M. Pidou, F. A. Memon and T. Stephenson, Greywater recycling: treatment options and applications, Proceedings of the Institution of Civil Engineers Engineering Sustainability 160, Issue ES3, September 2007. [13] Mr. Evalyne Cathy Arinaitwe, Suitable treatment of source separated greywater for discharge into an Urban Environment, Water and Environmental Engineering Department of Chemical Engineering Lund University May, 2018. [14] Meng Nan Chong, Kai Siang Oh and Janet Yip Cheng Leong, A review of greywater recycling related issues: Challenges and future prospects in Malaysia Kai, Journal of Cleaner Production, 171, 17-29, 2018. [15] N. R. Kulabakoa, N.K.M. Ssonkob and J. Kinobe, Greywater Characteristics and Reuse in Tower Gardens in Peri-Urban Areas – Experiences of Kawaala, Kampala, The Open Environmental Engineering Journal, 4, 147-154, 2011. [16] NarcisBarsan, HanenFilali, DalilaSouguir, ValentinNedeff, Claudia Tomozei and Mohamed Hachicha, Greywater as an Alternative Solution for a Sustainable Management of Water Resources A Review, Sustainability, 14, 665 2022. [17] Narayana J, Development of Cost-effective Waste Water Treatment Model for Sustainable Utilization of House Hold Waste Water, Acta Scientific Agriculture, 127-129, 2020. [18] SukumarDevotta, Manual Greywater Reuse in Rural Schools Wise Water Management, National Environmental Engineering Research Institute Nehru Marg, Nagpur - 440 020, India, January 2007. [19] SS Rakesh, Dr. PT Ramesh, Dr. R Murugaragavan, Dr. S Avudainayagam and Dr. S Karthikeyan, Characterization and treatment of grey water: A review, International Journal of Chemical Studies 8(1): 34-40, 2020. [20] Snehal Joshi, PritiPalande, Dr. Suneeti Gore, Ms. AnujaOke, Mrs. Gopika Manjunath, Dr. Chitra Naidu, Dr. Meenal Joshi, Purification of Grey water using the natural method, International Journal of Environment, Agriculture and Biotechnology Vol-7, Issue-2; Mar-Apr, 2022.
