Structural and Thermal Characterization of Geothermal Resources Using Aeromagnetic, Gravity, and Remote Sensing Data for Renewable Energy Exploration in Northeastern Chad Basin, Nigeria

Abstract

This study integrates aeromagnetic, gravity, and remote sensing datasets to assess the geothermal potential of the northeastern Chad Basin, Nigeria. The Total and residual magnetic intensity maps reveal magnetic anomalies ranging from 32918 to 33184.5 nT, and -58.7 to147.8nT linked to shallow intrusions and hydrothermally altered zones. Vertical derivative and analytic signal processing delineate structurally complex zones favorable for geothermal activity, while Source Parameter Imaging (SPI) and Curie Point Depth (CPD) analysis estimate geothermal gradients and heat flow, identifying high-potential blocks such as Block 2 and Block 6 with heat flows exceeding 340 mW/m² and Curie depths ranging from 8.49 to 19.87 km. Gravity data further support these findings by highlighting low-density anomalies and structural breaks that may enhance geothermal fluid movement, with Bouguer anomaly values ranging between -47.2 and -37.1 mGal. Remote sensing analysis identifies dense lineament trends (NE–SW and NW–SE), hydrothermal alterations, and high land surface temperatures, with LST values between 289.85 and 339.7 K, correlating with underlying geophysical anomalies. The integration of these methods confirms spatial consistency in geothermal indicators across geologically and structurally favorable zones, notably around Mafa (13°22?E, 12°08?N), Kesangala (13°25?E, 12°15?N), Monguno (13°37?E, 12°40?N), and Konduga (13°25?E, 11°57?N). These results underscore the basin’s elevated geothermal potential and provide a basis for targeted exploration and development

Introduction

1. Background and Significance:

• Geothermal energy is gaining global importance as a sustainable, base-load, low-carbon energy source.

• It is especially promising in energy-deficient regions like northeastern Nigeria, due to its continuous power potential and minimal environmental footprint.

• This study focuses on the Chad Basin in Nigeria, aiming to structurally and thermally characterize geothermal resources through integrated geophysical and remote sensing methods.

2. Methods Used:

A. Geophysical Techniques:

• Aeromagnetic Data: Helps detect subsurface structures such as faults and intrusions.

  • Techniques: First Vertical Derivative (FVD), Analytic Signal (AS), Source Parameter Imaging (SPI), Curie Point Depth (CPD) estimation using the centroid method.

• Gravity Data: Assesses density contrasts linked to geothermal sources.

  • Bouguer and residual gravity anomalies help map heat-related structures.

• Spectral Analysis: Used FFT on magnetic data from 16 blocks to determine Zt (top), Zo (centroid), and calculate CPD, geothermal gradient, and heat flow.

B. Remote Sensing Techniques:

• Landsat 9 thermal infrared (TIR) and multispectral data were used.

• Calculations included:

  • TOA Radiance, Brightness Temperature (BT)

  • NDVI, Proportion Vegetation (Pv), Surface Emissivity (ε)

  • Land Surface Temperature (LST)

• ASTER DEM was used to map lineaments and surface structural features.

3. Study Area and Geologic Setting:

• The region lies within Quaternary deposits (unconsolidated sand, clay, gravel).

• Covered areas include Konduga, Jere, Monguno, Mafa, Kilborani, Gajiram, and Ajiri.

• These deposits suggest young, flat terrains formed by sedimentary processes.

4. Results:

A. Magnetic and Structural Interpretation:

• TMI and RMI maps reveal magnetic anomalies, pointing to shallow intrusions and possible hydrothermal zones.

• FVD and AS maps identify structurally complex zones, conducive to geothermal activity.

• Lineament analysis reveals dominant NE–SW and NW–SE fault trends.

• SPI map shows source depths from 180–900 m, favorable for reservoir development.

B. Thermal Modelling (16 Blocks):

• Curie Point Depth (CPD): 3.94–8.48 km (avg. 6.28 km)

• Geothermal Gradient: 68.37–147.36 °C/km (avg. 96.42 °C/km)

• Heat Flow: 170.93–368.39 mW/m² (avg. 241.04 mW/m²)

• Blocks 2 and 6 (centered around 13.2°E, 12.2°N) show the most promising geothermal potential.

C. Thematic Maps:

• Curie Depth Map: Shallowest depths in central and southwestern regions (3.8–5.8 km), deeper in the northeast (>6.8 km).

• Geothermal Gradient Map: Highest gradients in southwest (~150°C/km), lowest in the northeast.

• Heat Flow Map: Highest values (>320 mW/m²) concentrated in the southwestern quadrant, indicating a geothermal anomaly.

5. Data Sources:

• Landsat 9 imagery and ASTER DEM from NASA/USGS.

• Gravity data from Bureau Gravimétrique International (BGI).

• Aeromagnetic data from Nigerian Geological Survey Agency (NGSA).

Conclusion

The integration of aeromagnetic, gravity, and remote sensing techniques has revealed a coherent geothermal framework within the northeastern Chad Basin. Magnetic data indicate shallow intrusions, fault zones, and high Curie point temperatures, particularly in the southwestern and central areas (12°00?N–12°30?N, 13°00?E–13°30?E), where elevated geothermal gradients and heat flows suggest viable geothermal reservoirs. Gravity anomalies confirm the presence of fractured, low density rocks and delineate major structural corridors aligned with mapped lineaments. Remote sensing data reinforce these findings by identifying areas of intense hydrothermal alteration, low vegetation indices, and high surface temperatures, especially in Mafa (13°22?E, 12°08?N), Kesangala (13°25?E, 12°15?N), and Kilborani (13°28?E, 12°20?N). The convergence of high heat flow, shallow Curie depths, significant structural deformation, and thermal anomalies strongly supports the presence of economically exploitable geothermal resources. This multidisciplinary approach provides a robust framework for future geothermal exploration in the region.

References

[1] Ajakaiye, D. E., Ojo, S. B., & Okereke, C. S. (1991). Crustal structure of the Benue Trough, Nigeria in relation to geothermal prospects. Tectonophysics, 34, 61–79. [2] Anakwuba, E. K., Chinwuko, A. I., Onuba, L. N., & Okolie, E. C. (2016). Estimation of heat flow and geothermal gradient from spectral analysis of aeromagnetic data over Gubio area, Chad Basin Nigeria. SN Applied Sciences, [3] Avbovbo, A. A. (1978). Geothermal gradients in the southern Nigerian Basin. Bulletin of Canadian Petroleum Geology, 26, 268–274. [4] Baioumy, H., & Tada, S. (2022). Geothermal energy exploration using remote sensing and geophysical data: A case study from the Eastern Desert, Egypt. Renewable Energy, 181, 1279–1293. https://doi.org/10.1016/j.renene.2021.09.085 [5] Blakely, R. J. (1996). Potential theory in gravity and magnetic applications. Cambridge University Press. [6] Chander, G., Markham, B. L., & Helder, D. L. (2009). Summary of current radiometric calibration coefficients for Landsat sensors. Remote Sensing of Environment, 113(5), 893–903. [7] DiPippo, R. (2015). Geothermal Power Plants: Principles, Applications, Case Studies and Environmental Impact. Butterworth-Heinemann. [8] DiPippo, R. (2016). Geothermal power generation: Developments and innovation. Woodhead Publishing. [9] Ebong, I. D., Ugwu, G. Z., & Igboekwe, M. U. (2022). Aeromagnetic modeling of heat flow potential in parts of the Lower Benue Trough, Nigeria. Geothermics, 103, 102428. [10] Eppelbaum, L. V., Kutasov, I., & Pilchin, A. (2014). Applied Geothermics. Springer. [11] Fedi, M., & Florio, G. (2001). Detection of potential field’s source boundaries by enhanced horizontal derivative method. Geophysical Prospecting, 49(1), 40–58. [12] Guha, A., Weng, Q., & Lo, C. P. (2013). Analysis of land surface temperature–vegetation patterns using MODIS satellite data. Environmental Earth Sciences, 68(8), 2399–2410. [13] Hinze, W. J., von Frese, R. R. B., & Saad, A. H. (2013). Gravity and Magnetic Exploration: Principles, Practices, and Applications. Cambridge University Press. [14] IEA. (2022). Geothermal power and heat. International Energy Agency. https://www.iea.org/reports/geothermal-power [15] Idris Nda, A., Musa, M., & Abdullahi, A. (2022). Application of remote sensing techniques for geothermal resource exploration in the Nigerian Chad Basin. Journal of Geosciences and Geomatics, 10(2), 87–94. [16] Jiménez-Muñoz, J. C., Sobrino, J. A., & Gillespie, A. (2009). Enhanced split-window algorithm for land surface temperature retrieval from remote sensing data. Remote Sensing of Environment, 112(6), 2367–2383. [17] Lawal, K. M., Onuba, L. N., Anakwuba, E. K., & Chinwuko, A. I. (2018). Geothermal energy potential evaluation from aeromagnetic data of parts of Chad Basin Nigeria. International Journal of Geophysics, 2018, 1–12. [18] Lund, J. W., & Boyd, T. L. (2016). Direct utilization of geothermal energy 2015 worldwide review. Geothermics, 60, 66–93. [19] Lund, J. W., & Toth, A. N. (2021). Direct utilization of geothermal energy 2020 worldwide review. Geothermics, 90, 102020. [20] Mallick, J., Kant, Y., & Bharath, B. D. (2008). Estimation of land surface temperature over Delhi using Landsat-7 ETM+. Journal of the Indian Geophysical Union, 12(3), 131–140. [21] Mogaji, K. A., Lim, H. S., Abdullar, K. B., & Aladesanmi, A. O. (2017). Integrated approach to geothermal exploration using geophysical and remote sensing techniques: Case study of North Central Nigeria. Journal of African Earth Sciences, 127, 27–44. [22] Musa, M., Usman, A. A., & Idris, A. N. (2023). Remote sensing-based identification of potential geothermal zones in Borno State, Nigeria. African Journal of Environmental Science and Technology, 17(5), 145–156. [23] Noorollahi, Y., Fadai, D., & Rosen, M. A. (2008). Geothermal energy development in Iran: A review of current status and future plans. Renewable and Sustainable Energy Reviews, 12(4), 1001–1009. [24] Noorollahi, Y., Itoi, R., Fujii, H., & Tanaka, T. (2008). GIS model for geothermal resource exploration in Akita and Iwate prefectures, northern Japan. Computers & Geosciences, 34(10), 1587–1597. [25] Nwankwo, C. N., Akpan, A. E., & Onwuemesi, A. G. (2012). Geothermal gradients and subsurface temperatures in the Anambra Basin, southeastern Nigeria. Journal of African Earth Sciences, 65, 73–78. [26] Nwankwo, C. N., Ugwu, G. Z., & Onuba, L. N. (2012). Estimation of geothermal gradients and heat flow in the Sokoto Basin of Northwestern Nigeria. Journal of Applied Geophysics, 88, 1–8. [27] Onuoha, K. M., & Kingston, G. S. (1989). Heat flow and geothermal gradient in the Anambra Basin of Nigeria. Geothermics, 18(2), 165–175. [28] Onuoha, K. M., & Ofoegbu, C. O. (1985). Crustal thickness in the Chad Basin, Nigeria, from gravity interpretation. Geophysics, 50(2), 326–333. [29] Pettorelli, N., et al. (2005). Using NDVI to assess ecological responses to environmental change. Trends in Ecology & Evolution, 20(9), 503–510. [30] Quintero, R., Muñoz, G., & Martínez, R. (2019). Integration of gravity, magnetic and remote sensing data for geothermal exploration in the Andes. Geothermics, 80, 123–134. [31] Reeves, C. V. (2005). Aeromagnetic Surveys: Principles, Practice and Interpretation. Geosoft Inc. [32] Sadeghi, H., Noorollahi, Y., & Ghasemi, H. (2023). Integration of remote sensing and geophysical data in geothermal exploration: A case study. Renewable Energy, 205, 1007–1021. [33] Sandwell, D. T., Müller, R. D., Smith, W. H. F., Garcia, E., & Francis, R. (2013). New global marine gravity model from CryoSat-2 and Jason-1 reveals buried tectonic structure. Science, 346(6205), 65–67. [34] Sobrino, J. A., Jiménez-Muñoz, J. C., & Paolini, L. (2004). Land surface temperature retrieval from LANDSAT TM 5. Remote Sensing of Environment, 90(4), 434–440. [35] Sobrino, J. A., Jiménez-Muñoz, J. C., & Paolini, L. (2004). Land surface temperature retrieval from Landsat TM 5. Remote Sensing of Environment, 90(4), 434–440. [36] State, N. M. (2021). Nigeria’s Renewable Energy Master Plan: Review and recommendations. Nigerian Energy Commission. https://www.energy.gov.ng [37] Telford, W. M., Geldart, L. P., & Sheriff, R. E. (1990). Applied Geophysics (2nd ed.). Cambridge University Press. [38] Tucker, C. J. (1979). Red and photographic infrared linear combinations for monitoring vegetation. Remote Sensing of Environment, 8(2), 127–150. [39] Weng, Q. (2009). Thermal infrared remote sensing for urban climate and environmental studies: Methods and applications. ISPRS Journal of Photogrammetry and Remote Sensing, 64(4), 335–344. [40] Yaya, A., Alabi, A. A., & Alao, S. A. (2021). Curie point depth and geothermal assessment using gravity data: A case study of the northern Nigerian Chad Basin. International Journal of Science and Research (IJSR), 10(5), 1330–1339.
