Use of Outriggers in Tall Structure Building: A Review

Abstract

The rising demand for high-rise and aesthetically captivating structures with vertical and horizontal irregularities, unique architectural themes, and increasing heights has introduced new challenges and necessitated the implementation of advanced safety measures. To resist earthquakes and the significant impact of wind caused by increasing building height, preventive structural systems need to be adopted, as the stiffness of the structure increases with its tallness. Bracings, shear walls, and outrigger systems are some of the structural mechanisms used for stability. In this study, the outrigger system is analyzed, as it is considered the most optimal solution for high-rise buildings and skyscrapers. In this system the external columns are connected to main inner or outer core by means of outrigger wall at different floors that resist entire structure against collapse and rotating action of core due to worst horizontal effects seismic and wind forces. In this study various papers allied to this topic are reviewed in which an enormous work is done in this field earlier. With the help of review of research paper we came to know about the conclusive outcome which forms the research objectives of our further study.

Introduction

Tall structures (high-rise/skyscrapers) are built to accommodate dense urban populations and commercial needs but face challenges like structural instability, wind, seismic forces, and fire hazards. Advances in materials, structural systems, and sustainable design have improved their safety and resilience. Among structural systems, the outrigger system is widely used to enhance stability by connecting the building’s core to outer columns, reducing lateral deflections and improving stiffness, often combined with dampers for vibration control. This system also allows for more open interior spaces and flexible architecture.

The literature review covers numerous studies analyzing outrigger systems and other lateral load-resisting mechanisms using software like ETABS and Staad Pro. Key findings include:

• Optimal outrigger placement (often around mid-height) greatly improves performance under wind and seismic loads.

• Different outrigger configurations (X, V, inverted V, shear walls with belts) affect building responses; the inverted V and shear wall belts tend to perform best.

• Addressing construction issues like differential shortening in outriggers is critical.

• Terrain and local seismic/wind conditions strongly influence structural responses.

• Comparative studies of bracing, diagrid, and outrigger systems show outriggers often provide superior lateral stability.

• High-rise buildings in seismic zones benefit significantly from outriggers combined with wall belts or trusses.

• Studies also explore the impact of concrete grades and irregular building shapes on system effectiveness.

• Research emphasizes ongoing optimization of outrigger placement and configuration to maximize safety, stiffness, and occupant comfort.

• The outrigger system remains a cost-effective, adaptable, and essential technology for modern supertall buildings worldwide.

Conclusion

It seems that there is a research gap in the literature regarding the different analysis and design work done previously on seismic method of analysis, Gust factor method of wind analysis and analysis of Tall structure building. Based on the literature review, we have reached a conclusion that highlights the key findings of the research and lists the necessary outcomes: 1) It is essential to compare the Gust factor of wind analysis with response method of seismic analysis. 2) Conducting a study on comparison over Tall structurewith Outrigger system. 3) It is important to use recommend the recommendations followed by IS 1896:2016 for seismic analysis and IS 875 part III for wind analysis of the structure over medium soil conditions. 4) To ensure accuracy in the analysis, it is recommended to use outrigger for increasing stability with different cases and its usage over different floor levels. 5) Different parameters such as Displacements, Base shear, Axial Forces, Bending moments and Shear forces since these parameters should be necessary to determine the behavior of a building structure. The primary objective of this study is to determine the further research needed to investigate the comparative effect of gust factor method and seismic analysis that justify the impact of use of outrigger on tall structure building to see the behavior of the structural performance that has going to be a major study for upcoming proposed work.

References

[1] Kiran Kamath et. al. (2012), “A Study on Static and Dynamic Behavior of Outrigger Structural System for Tall Buildings”, Bonfring International Journal of Industrial Engineering and Management Science, ISSN 2277-5056, Vol. 2, No. 4, pp- 15-20. [2] Kwang Rang Chung et. al., (2015), “Outrigger systems for Tall Buildings in Korea”, International Journal of High Rise Buildings, Volume: 04 Issue: 03, pp. 209-217. [3] Suraj Nayak U et. al. (2016), “Effect of Static and Dynamic Wind Forces on RC Tall Structures at different Height, in different Zones and in different Terrain Category using Gust Factor Method As Per Is: 875 (Part 3) 1987”, International Journal of Modern Engineering Research, ISSN: 2249–6645, Vol. 6, issue 3, pp. 47-61. [4] Abeena mol N M,et. al., (2016), “Performance Of Different Outrigger Structural Systems”, International Research Journal of Engineering and Technology (IRJET), ISSN 2395-0056, Volume: 03, Issue: 09, pp. 1104-1107. [5] Dattaprasad Patil et. al. (2018), “Comparative Study of RC Framed Structure and Tubular Structures”, International Journal of Scientific Research in Science, Engineering and Technology, ISSN: 2394-4099, Volume 4, Issue 8, pp.475-481. [6] Pankaj Sharma et. al. (2018), “Dynamic Analysis Of Outrigger Systems In High Rise Building Against Lateral Loading”, International Journal of Civil Engineering and Technology (IJCIET), ISSN Print: 0976-6308, Volume 9, Issue 8, pp. 61-70. [7] Neeraj Patel et. al. (2019), “Use of Shear Wall Belt at Optimum Height to Increase Lateral Load Handling Capacity in Multistory Building: A Review”, International Journal of Advanced Engineering Research and Science (IJAERS), ISSN: 2349-6495, Vol-6, Issue-4, pp. 310-314. [8] Archit Dangi et. al. (2019), “Determination of Seismic parameters of R.C.C. Building Using Shear Core Outrigger, Wall Belt and Truss Belt Systems”, International Journal of Advanced Engineering Research and Science (IJAERS), ISSN: 2349-6495, Vol-5, Issue-9, pp. 305-309. [9] Neeraj Patel et. al., (2019), “Use of Shear Wall Belt at Optimum Height to Increase Lateral Load Handling Capacity in Multistory Building”, International Journal for Research in Engineering Application & Management (IJREAM), ISSN: 2454-9150 Vol-04, Issue-10, pp. 596-603. [10] Ashitha V Kalam et. al. (2019), “Dynamic Wind Analysis Of RC Bundled Tube In Tube Structure Using Etabs”, International Research Journal of Engineering and Technology (IRJET), ISSN: 2395-0056, Volume: 06, Issue: 05, pp.7457-7462. [11] Archit Dangi et. al. (2019), “Stability Enhancement of Optimum Outriggers and Belt Truss Structural System”, International Research Journal of Engineering and Technology (IRJET), ISSN: 2395-0056, Volume: 06 Issue: 02, pp.772-780. [12] Sakshi Goyal, et. al. (2020), “Stability Increment Practices using Wall Outrigger Members: A Review”, International Journal for Research in Applied Science & Engineering Technology (IJRASET), ISSN: 2321-9653, Volume 8, Issue VI, pp. 1656-1661. [13] Mohammad Bilal Rasheed et. al., (2020), “Conceptual Approach on Effect of Various Concrete Grade in Outrigger and Wall Belt Supported System: A Perceptional Review”, International Journal of Advanced Engineering Research and Science (IJAERS), ISSN: 2349-6495, Vol-7, Issue-5, pp. 100-104. [14] Mustafa Hussaini, et. al. (2020), “Seismic Performance of Bracing, Diagrid and Outrigger System”, International Journal of Innovative Technology and Exploring Engineering (IJITEE), ISSN: 2278-3075, Volume-9 Issue-7, pp. 32-36. [15] Rasheed Altouhami et. al. (2020), “Wind Effect On Difference Shear Wall Position With Different Shape Configuration”, Third International Conference on Technical Sciences (ICST2020), 28 – 30 November 2020, Tripoli – Libya. [16] Mohammad Bilal Rasheed et. al., (2020), “An Efficient Approach to Determine the Effects of Different Grades of Concrete in Outrigger and Wall Belt Supported System”, International Journal for Research in Applied Science & Engineering Technology (IJRASET), ISSN: 2321-9653, Volume 8, Issue VII, pp. 1833-1842. [17] Sakshi Goyal et. al. (2020), “Analytical Practices to Obtain Efficient Concrete Grade in Outrigger Walls below Plinth Level in Multistorey Building”, International Journal of Advanced Engineering Research and Science (IJAERS), ISSN: 2349-6495, Vol-7, Issue-7, pp. 367-374. [18] Palak Joshi et. al., (2021), “Dynamic Analysis of Tubular Systems in Tall Buildings”, International Research Journal of Engineering and Technology (IRJET), ISSN: 2395-0056, Volume: 08, Issue: 11, pp. 655-662. [19] Mohammed Sanaullah Shareef, et. al. (2022), “Dynamic Analysis of High-Rise Structures with Outrigger Structural System Subjected To Lateral Loads”, IOP Conf. Series: Earth and Environmental Science, ICSDI-2022, 012010. [20] Mohammed Mudabbir Ahmed et. al. (2022), “A Comparative Study On The Seismic Performance Of Multi-storey Buildings With Different Structural Systems”, IOP Conf. Series: Earth and Environmental Science, ICSDI-2022, 012010. [21] IS 456: 2000, “Plain and Reinforced Concrete – Code of Practice”, Fourth revision, Bureau of Indian Standards, New Delhi, India. [22] IS: 875(Part 1)-1987, “Code of Practice for Design loads (other than Earthquake) for Buildings and Structures”, Part 1 Dead Loads — Unit Weights of Building Materials and Stored Materials, Second revision, Bureau of Indian Standards, New Delhi, India. [23] IS: 875(Part 2)-1987, “Code of Practice for Design loads (other than Earthquake) for Buildings and Structures”, Part 2 Imposed Loads, Second revision, Bureau of Indian Standards, New Delhi, India.
