Analysis and Design of G+15 Building With Connecting Skywalk in Gorakhpur

Authors: Rishabh Singh

DOI Link: https://doi.org/10.22214/ijraset.2023.55082

Certificate: View Certificate

Abstract

The structural analysis and design of G+15 building with the connection skywalk is done using software StaddPRO V8i. The planning is done in AUTOCAD 2019. The G+15 building with the connection skywalk which connect the two buildings to facilitates the movement of the people inside the building. The plan of the G+15 building will be drawn. The analysis of the speed, quality and construction aspects will be done. The building will be designed as per the IS codes. The various loads acting on the G+15 building will be calculated based on the Indian Standard Code books. It gives a platform to work hand to hand with the people of other department such IT department. The building will be designed keeping the economic aspect in mind with sufficient durability and strength.

Introduction

I. INTRODUCTION

The high rise building concept which is the demand of the future generation. We are moving toward the era where the land is less and the population demand is quite high. To meet the basic demand of each individual human being was residence which can be fulfilled by the making the high rise building. The tall building can fulfill the demand. They save space and accommodate more residents as compared to individual houses. Tall buildings provide a aesthetic and a modern look to the city. Due to much space inside of the building it could fit more than one company in it. Hence saves much space in the city. Another advantage of the tall building is that it can saves more land for agricultural purpose. Hence in

this project we have planed, analysed and designed the G+15 building with the connection skywalk which connect the two buildings to facilitates the movement of the people inside the building. The successful construction of G+15 buildings are based upon clear understanding of the conduct of the structure, relevant analysis theory and methodologies, use of software, and explicit design principles.

II. PLANNING

This building was being made in the location of taramandal which is located in the Gorakhpur, Uttar Pradesh. The location coordinates of the site is 26°43'54.6"N 83°22'53.2"E and the altitude is 73.7176827. The total plot area required for this peoject was 9000m2. The total height of the building is 48 m. The building connecting skywalk at the 8th floor of the building which is of 9 m in length. The building project was economical and this project help us to understand the various components of the building and the loads acting on the building and their effects on the building. And to design the structural components like slab, beam,

column, foundation of the G+15 building. The plan of the G+15 building will be drawn. The analysis of the speed, quality and construction aspects will be done. The various loads acting on the G+15 building will be calculated based on the Indian Standard Code books. It gave us the opportunity to work with the other department students which help us to gain knowledge.

Conclusion

The Planning, analysis and design of G + 15 building is done successfully. The methodology and plan for a G + 15 building is presented in this project. Limit state of method has been used as the method for the design of the building. The successful construction of G+15 buildings are based upon clear understanding of the conduct of the structure, relevant analysis theory and methodologies, use of software. They take longer to build and are generally 25-40% more expensive per square meter than a low-rise building. It will increase the pollution caused during the construction of a building. Hence followed the NBC guide lines during the construction. The design of joints connecting slabs and RC walls is designed constrain.

References

[1] B.Gireesh babu,”seismic analysis and design of G+7 Residential building using STAAD.Pro;” international journal of advance research ,ideas and innovations in technologyISSN:2454132X,volume3,issue3,2017. [2] Mohit Sharma, Dr. Savita Maru,” Dynamic Analysis of Multi-storey Regular Buildings IOSR Journal of Mechanical Engineering and Civil Engineering (IOSR-JMCE). Volume 11, Issue 1 Ver. II (Jan. 2014). [3] Prof. S.S. Patil, Miss. S.A. Ghadge, Prof. C.G. Konapure, Prof. Mrs. C.A. Ghadge, “Seismic Analysis of Multi-storey Building” International Journal Of Computational Engineering Research (Ijceronline.Com) Vol. 3 Issue. 3.march 2013. [4] Mahesh N. Patil , Yogesh N. Sonawane. “Seismic analysis of multi-storeyed buildings (IJEIT) Volume 4, Issue 9, March 2015. [5] Anoop singh, Vikassrivastava, N.N. Harry. “Seismic and design of building structure using STADD.pro “International Journal of Innovative Research in Science, Engineering and Technology, Vol. 5, Issue 7, July 2016. [6] Aman, Manjunath Nalwadgi, Vishal T, Gajendra. “Analysis and design of multi-storey building” International Research Journal of Engineering and Technology ,Volume: 03 Issue: 06 | June-2016. [7] Girum mindaye , Dr. shaik yajdani. “Seismic Analysis of Multi-storey RC Frame Buildings in many Seismic Zone “,International Journal of Innovative Research in Science,Engineering and Technology. Vol. 5, Issue 9, September 2016. [8] E. Pavan Kumar, A. Naresh, M. Nagajyothi ,M. Rajasekhar ,”Earthquake analysis of multi-stored residential building case study”, Int. Journal of Engineering Research and Applications . Vol. 4, Issue 11, November 2014. [9] Anoj Surwase1, Dr. Sanjay K. Kulkarni 2, Prof. Manoj Deosarkar3 “Seismic Analysis and Comparison of IS 1893 (Part-1) 2002 and 2016 of (G+4) Regular and Irregular Building” International Journal of Innovative Research in Science, Engineering and Technology Vol. 7, Issue 6, June 2018 [10] Gauri G. Kakpure*, Dr. A. R. Mundhada “Comparative Study of Static and Dynamic Seismic Analysis of Multistoried RCC Buildings by ETAB Int. Journal of Engineering Research and Application; ISSN: 2248-9622, Vol. 7, Issue 5, ( Part -5) May 2017, IJESC, June 2019 23057 http://ijesc.org/

Copyright

Copyright © 2023 Rishabh Singh. This is an open access article distributed under the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.
